Description

Manhattan HDMI Splitter 2-Port , 1080p, Black, Displays output from x1 HDMI source to x2 HD displays (same output to both displays), USB-A Powered (cable included, 0.7m), Three Year Warranty, HDMI, 2x HDMI, 1.3b, 1920 x 1200 pixels, Black, Plastic

Easily distribute a single HDMI signal to multiple displays._x000D_ The Manhattan 1080p 2-Port HDMI Splitter sends HDMI signals from a single Blu-ray player, satellite receiver, digital recorder, set-top box, game console or other HDMI source to two HDMI displays. _x000D_ _x000D_ Flexible Solution for Many A/V Applications_x000D_ Ideal for trade shows, classrooms, video conferencing, presentations and retail applications, the Manhattan 1080p 2-Port HDMI Splitter features a built-in booster for added signal strength. It’s also a good choice for splitting and distributing a synchronous signal to multiple HDMI displays when source equipment is remotely stored in a secured room or cabinet. Users can cascade multiple units up to three levels and output HDMI video/audio to additional displays in widely distributed applications._x000D_ _x000D_ Quality Construction and Easy Installation_x000D_ Full compliance with HDMI, HDCP 1.0, 1.1 and 1.2 as well as DVI 1.0 ensures that the Manhattan 1080p 2-Port HDMI Splitter can provide long service and reliable performance. Quickly connect HDMI cables (not included) and the USB power cable, and this affordable HDMI solution is complete — no complicated settings or software or hardware configurations necessary.

Specifications

BrandMANHATTAN
Manufacturer part no.207652
Our part no.0Z31874
EAN0766623207652
CategoryCables & Adapters › HDMI Cables & Extenders
Weight0 kg
Ports & interfaces
Video port typeHDMI
Video out2x HDMI
HDMI version1.3b
Video ports quantity3
Features
Product colourBlack
Housing materialPlastic
Maximum resolution1920 x 1200 pixels
3DYes
Maximum operating distance15 m
Bandwidth225 MHz
Cable length0.7 m
HDCPYes
Connector contacts platingGold
Plug and PlayYes
LED indicatorsYes
Dolby technologiesDTS, DTS-HD Master Audio, Dolby TrueHD
CertificationCE, FCC, RoHS2
Power
Power consumption (typical)5 W
USB poweredYes
Weight & dimensions
Width54 mm
Depth60 mm
Height20 mm
Weight40 g
Packaging content
ManualYes
Cables includedUSB
Operational conditions
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-10 - 80 °C
Operating relative humidity (H-H)10 - 85%
Storage relative humidity (H-H)5 - 90%
Technical details
Compliance certificatesCE, RoHS, Federal Communications Commission (FCC)
Logistics data
Harmonized System (HS) code85176990
