Description

Epson TM-J7700(301) W/O MICR, BLACK, INC PSU, UK, Inkjet, POS printer, 98 mm/sec, 58 - 83 mm, Wired, USB Type-B

Versatile POS printer Designed to offer maximum performance and minimum running costs in retail environments, the TM-J7700 multifunctional POS printer uses inkjet technology to print receipts as well as slips, forms and coupons, with sharp, durable results.

Faster, better inkjet technology Inkjet technology means that not only are printouts more detailed (600dpi compared to 180dpi for existing models), they’re around twice as fast too, with a print speed of 100mm/s (23.2lps) compared to 43mm/s (13.5lps) for previous models.

Low TCO Epson has managed to incorporate inkjet technology into this new model while retaining a similar low total cost of ownership to previous dot matrix printers.

Simple maintenance The ink cartridges have an easy-install design ideal for busy retail counters, as well as drop-in paper roll for quick loading, and the ink formulation used offers better water and light resistance than dot matrix, so receipts and documents will last longer.

Backwards compatible To make upgrading from existing models incredibly easy, the TM-J7700 is fully backwards-compatible with the TM-J7500 and has exactly the same footprint, so it can simply be swapped in. However, to integrate smoothly with the latest ePOS systems, the model offers both USB and Ethernet connection options.

Specifications

BrandEPSON
Manufacturer part no.C31CF70301A0
Our part no.235P531
CategoryLabel & Receipt Printers › Receipt Printers
Weight7.8 kg
Printing
Print speed98 mm/sec
Print technologyInkjet
TypePOS printer
Paper handling
Supported paper width58 - 83 mm
Ports & interfaces
USB portYes
USB connectorUSB Type-B
Connectivity technologyWired
Standard interfacesUSB 2.0
InterfaceUSB 2.0, Ethernet interface (100 Base-TX / 10 Base-T), Drawer kick-out, Customer Display
Network
Ethernet LANYes
Wi-FiNo
Features
Sound pressure level (printing)55 dB
Mean time between failures (MTBF)180000 h
CutterYes
Autocutter durability1.5 million cuts
Country of originIndonesia
SafetyTÜV, TÜV (EN60950-1)
CertificationCE, EN55024, EN55032 A, IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-11
Design
Product colourBlack
Power
Power consumption70000 mA
DC output voltage24 V
Operational conditions
Operating temperature (T-T)10 - 35 °C
Storage temperature (T-T)-20 - 40 °C
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)20 - 85%
Weight & dimensions
Width251 mm
Depth260 mm
Height188 mm
Weight5.8 kg
Packaging data
Cables includedAC, USB
Quantity per pack1 pc(s)
Package width350 mm
Package depth390 mm
Package height310 mm
Package weight7.88 kg
Packaging content
AC adapter includedYes
Logistics data
Harmonized System (HS) code84433210
Products per pallet36 pc(s)
Products per pallet layer6 pc(s)
Pallet gross width80 cm
Pallet gross length120 cm
Pallet gross height111 cm
Products per pallet (UK)36 pc(s)
Products per pallet layer (UK)6 pc(s)
Pallet length (UK)120 cm
Pallet height (UK)111 cm
Technical details
Box contentsCD Manual, Ink Cartridge, PS-180, Power cable, Power switch cover, Roll paper, Setup guide, USB cable, User manual (CD)
