APC Symmetra LX 16kVA N+1 uninterruptible power supply (UPS) 11200 W 1 AC outlet(s)

Description

APC Symmetra LX 16kVA N+1, 16 kVA, 11200 W, 155 V, 480 V, 50/60 Hz, 220 V

APC Symmetra, 11.2 kW / 16 kVA, Input 230V, 400V 3PH / Output 230V , Interface Port DB-9 RS-232, Smart-Slot

Includes: CD with software, Documentation CD, Installation guide, User Manual, Web/SNMP Management Card

Standard Lead Time: Usually in Stock

Specifications

BrandAPC
Manufacturer part no.SYAF16KI
Our part no.2702596
CategoryPower & UPS › UPS
Weight0 kg
Features
Output power capacity16 kVA
Output power11200 W
Input operation voltage (min)155 V
Input operation voltage (max)480 V
Input frequency50/60 Hz
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Efficiency90%
Crest factor5:1
Emergency Power Off (EPO)Yes
Output voltage Total Harmonic Distortion (THD)5%
Noise level62 dB
Audible alarm(s)Yes
Ports & interfaces
AC outlets quantity1 AC outlet(s)
RS-232 ports1
Battery
Battery technologySealed Lead Acid (VRLA)
Design
Form factorTower
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 4500 m
Safety regulation & standards
SafetyC-tick, CE, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 55024, EN 60950, GOST, IEC 60950, VDE
Weight & dimensions
Width483 mm
Depth726 mm
Height937 mm
Weight116.4 kg
Packaging data
Package weight147.7 kg
Other features
Battery typeSYBT5
Dimensions (WxDxH)483 x 726 x 937 mm
Nominal output voltage230 V
Nominal input voltage230-400 V
Package dimensions (WxDxH)599 x 997 x 1181 mm
