Description
APC Symmetra LX 8kVA N+1, 8 kVA, 5600 W, 155 V, 480 V, 50/60 Hz, 220 V
APC Symmetra, 5600 Watts / 8000 VA, Input 230V, 400V 3PH / Output 230V , Interface Port DB-9 RS-232, Smart-Slot , Extended runtime model
Includes: CD with software, Documentation CD, Installation guide, User Manual, Web/SNMP Management Card
Standard Lead Time: Usually in Stock
Specifications
| Brand | APC |
|---|---|
| Manufacturer part no. | SYAF8KI |
| Our part no. | 2702603 |
| Category | Power & UPS › UPS |
| Weight | 0 kg |
| Features | |
| Output power capacity | 8 kVA |
| Output power | 5600 W |
| Input operation voltage (min) | 155 V |
| Input operation voltage (max) | 480 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Efficiency | 90% |
| Crest factor | 5:1 |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Input current Total Harmonic Distortion (THD) | 7% |
| Noise level | 62 dB |
| Ports & interfaces | |
| AC outlets quantity | 1 AC outlet(s) |
| RS-232 ports | 1 |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 3 h |
| Design | |
| Form factor | Tower |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 4500 m |
| Safety regulation & standards | |
| Safety | C-tick, CE, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 55024, EN 60950, GOST, IEC 60950, VDE |
| Weight & dimensions | |
| Width | 483 mm |
| Depth | 726 mm |
| Height | 671 mm |
| Weight | 201.8 kg |
| Packaging data | |
| Package weight | 229.6 kg |
| Other features | |
| Battery type | SYBT5 |
| Dimensions (WxDxH) | 483 x 726 x 671 mm |
| Nominal output voltage | 230 V |
| Nominal input voltage | 230-400 V |
| Package dimensions (WxDxH) | 599 x 997 x 914 mm |
