Description
APC SMT3000RM2U, 3 kVA, 2700 W, 75 V, 154 V, 50/60 Hz, 120 V
Intuitive LCD interface Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
Predictive replace battery date Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
Green mode Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
Energy meter Provides actual kilowatt hours of usage for energy conscious users.
Outlet group control Turn on/off, reboot or shut down select outlet groups to save dispatching technicians to remote locations (for UPSs with switched outlet groups).
Sequenced shutdown and restart Configure select outlet groups to shut down and turn on in a pre-determined order (for UPSs with switched outlet groups).
InfraStruXure Central compatible Enables centralized management via APC InfraStruXure® Central.
Pure sine wave output on battery Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
Single switched outlet group Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
Sine wave output Eliminates humming and heat generated when powering tubelights and fans.
Battery failure notification Provides early-warning fault analysis on batteries enabling timely preventive maintenance
LED Indicators Provide easy-to-read status of the unit and utility power conditions.
Hot-swappable batteries Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Disconnected battery notification Warns when a battery is not available to provide backup power.
Specifications
| Brand | APC |
|---|---|
| Manufacturer part no. | SMT3000RM2U |
| Our part no. | 2709181 |
| Category | Power & UPS › UPS |
| Weight | 52 kg |
| Features | |
| Output power capacity | 3 kVA |
| Output power | 2700 W |
| Input operation voltage (min) | 75 V |
| Input operation voltage (max) | 154 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 120 V |
| Output operation voltage (max) | 120 V |
| Surge energy rating | 459 J |
| Efficiency | 98% |
| Noise level | 55 dB |
| Audible alarm(s) | Yes |
| Ports & interfaces | |
| AC outlet types | NEMA 5–15R, NEMA 5–20R |
| AC outlets quantity | 8 AC outlet(s) |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 3 h |
| Design | |
| Form factor | Rackmount |
| Rack capacity | 2U |
| Cable length | 2.44 m |
| Product colour | Black |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
| Certificates | |
| Certification | CSA,FCC 15 A,UL 1778 |
| Weight & dimensions | |
| Width | 480 mm |
| Depth | 683 mm |
| Height | 86 mm |
| Weight | 44.3 kg |
| Packaging data | |
| Package weight | 51.7 kg |
| Other features | |
| Battery type | RBC43 |
| Interface | USB |
| Nominal output voltage | 120 V |
| Nominal input voltage | 120 V |
| Package dimensions (WxDxH) | 600 x 980 x 254 mm |
