APC SRV10KRILRK uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W

Description

APC SRV10KRILRK, Double-conversion (Online), 10 kVA, 10000 W, Pure sine, 110 V, 300 V

High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions.

Includes: CD with software, USB cable, User Manual.

Specifications

BrandAPC
Manufacturer part no.SRV10KRILRK
Our part no.270D215
EAN0731304346180
CategoryPower & UPS › UPS
Weight106.5 kg
Features
UPS topologyDouble-conversion (Online)
Output power capacity10 kVA
Output power10000 W
WaveformPure sine
Input operation voltage (min)110 V
Input operation voltage (max)300 V
Input frequency40/70 Hz
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Output frequency50/60 Hz
Surge energy rating600 J
Crest factor3:1
ECO modeYes
Emergency Power Off (EPO)Yes
Audible alarm(s)Yes
Audible alarm modesLow battery alarm, Overload alarm
Auto-restartYes
Ports & interfaces
AC outlet typesHard Wire 3-wire (1PH + N + G)
USB portYes
Serial interfaceYes
Emergency Power Off (EPO) connectorYes
SmartSlotYes
SmartConnect portNo
Battery
Hot-swap batteryYes
Automatic battery testYes
Design
Form factorRackmount
Rack capacity5U
Product colourBlack
Display typeLCD
LED indicatorsYes
Operational conditions
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 14763 m
Certificates
Compliance certificatesRoHS
CertificationCE, IEC 62040-1-1, IEC 62040-1-2 REACH
Packaging content
Cables includedUSB cable
Management card includedNo
ManualYes
Weight & dimensions
Width438 mm
Depth615 mm
Height220 mm
Weight78 kg
Packaging data
Package weight79 kg
Logistics data
Harmonized System (HS) code85078000
Other features
Nominal output voltage230 V
Nominal input voltage230 V
