Description
Allied Telesis DRB15, 85 - 264 V, 47 - 63 Hz, 0.27 A, 20 ms, 90%, Over current, Over voltage
The DRB series are DIN Rail Power Supplies operating at 24-48V (Depending on Model). These power supplies are ideal for low power applications that require basic functionality. They have been designed to support the growing trend for simple and economic DIN power solutions in industrial, building automation and process control applications. The DRB Series combines extremely compact dimensions with industry leading efficiency of up to 91%.
Housed in a robust plastic case, these power supplies feature a narrow design, saving space on the DIN rail. It operates from a universal input of 85 to 264V AC and have EN61000-3- 2 compliance, enabling worldwide use. They can withstand a voltage of 300V AC surge for 5 seconds.
Specifications
| Brand | ALLIED TELESIS |
|---|---|
| Manufacturer part no. | AT-DRB15-24-1 |
| Our part no. | 425B121 |
| Category | Computers & Servers › Power Supplies |
| Weight | 0.1 kg |
| Power | |
| AC input voltage | 85 - 264 V |
| AC input frequency | 47 - 63 Hz |
| Maximum input current (@110V) | 0.27 A |
| Power factor | 0.55 |
| Hold time | 20 ms |
| Efficiency | 90% |
| Power protection features | Over current, Over voltage |
| Design | |
| Product colour | Blue |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Certificates | |
| Certification | UL508 Listed, UL60950-1, CSA22.2 No60950-1, EN60950-1, CE Mark |
| Weight & dimensions | |
| Width | 18 mm |
| Depth | 90 mm |
| Height | 75 mm |
