Description
SilverNet Base 500, Network bridge, 500 Mbit/s, Wi-Fi, Ethernet LAN, Wall mountable, White
The SIL BASE 500 is a Multipoint receiver with 2 external antenna connectors. It can be used in a multipoint system or as a long range Point to Point link. The SIL BASE 500 is capable of up to 500Mbps up to 5km (depending on which external antenna is fitted).
When fitted with a Dual polarised Omni or Sector antenna the SIL BASE 500 can be used as a Multipoint receiver, receiving signals from multiple clients at the same time.
The SIL BASE 500 can also be used as a long range Backhaul link when fitted with Dish or Grid antennas.
Please see our Antenna Datasheet for available antennas.
Specifications
| Brand | SILVERNET |
|---|---|
| Manufacturer part no. | SIL BASE 500 |
| Our part no. | 4M30070 |
| Category | Networking › Wireless Access Points |
| Weight | 0 kg |
| Data transmission | |
| Maximum data transfer rate | 500 Mbit/s |
| Supported data transfer rates | 95, 240, 500Mbps |
| Antenna | |
| Antenna design | External |
| Antenna connector type | N-type |
| Antennas quantity | 1 |
| Wireless LAN features | |
| Wi-Fi | Yes |
| Wi-Fi band | Single-band (5 GHz) |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 867 Mbit/s |
| Frequency band | 5.1 - 5.8 GHz |
| Modulation | 16-QAM, 64-QAM, 256-QAM, BPSK, QPSK |
| Receiver sensitivity | -82dBm@54Mbps, -74dBm@300Mbps, [email protected] |
| Output power (dBm) | 26 |
| Indoor range | 5.1GHz - 5.7Ghz |
| Outdoor range | 5.4GHz - 5.8GHz |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.11i, IEEE 802.1Q, IEEE 802.1x |
| Cabling technology | 10/100/1000Base-T(X) |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Static IP | Yes |
| Dynamic IP | Yes |
| Ports & interfaces | |
| Connectivity technology | Wired & Wireless |
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
| Security algorithms | 256-bit AES, SNMPv2 |
| Security features | 802.1x, 802.11i, 802.1Q |
| MAC address filtering | Yes |
| Authentication method | WPA2 AES |
| Management features | |
| Management platform | SNMP V2 |
| Web-based management | Yes |
| DHCP client | Yes |
| Features | |
| Product type | Network bridge |
| Product colour | White |
| Remote control function | Yes |
| LED indicators | LAN, Signal strength |
| Automatic Transmit Power Control (ATPC) | Yes |
| Wall mountable | Yes |
| Reset button | Yes |
| International Protection (IP) code | IP67 |
| Surge protection | Yes |
| Quality of Service (QoS) support | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Network Time Protocol (NTP) client | Yes |
| Mean time between failures (MTBF) | 60000 h |
| System requirements | |
| Minimum system requirements | Internet Explorer, Google Chrome, Mozilla Firefox |
| Compatible operating systems | Microsoft Windows, Mac OS, Linux Distributions |
| Power | |
| Power source type | DC, PoE |
| AC input voltage | 100 - 240 V |
| Power supply | 15.4 W |
| DC input voltage | 24 - 48 V |
| Power consumption (typical) | 6 W |
| Power consumption (max) | 16 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) voltage | 48 V |
| Power plug type | Type G |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | -4 - 158 °F |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -40 - 90 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Certificates | |
| Certification | CE, FCC |
| Weight & dimensions | |
| Width | 220 mm |
| Depth | 75 mm |
| Height | 220 mm |
| Weight | 1.6 kg |
| Packaging content | |
| Packaging content | Includes 1 x radio, 1 x PoE injector PSU and 1 x Tilt and Swivel 3 Axis mounting bracket. |
| Grounding | Yes |
| PoE+ Injector(s) | Yes |
| Mounting bracket(s) included | Yes |
| Power supply included | Yes |
| Quick installation guide | Yes |
| Packaging data | |
| Package width | 307 mm |
| Package depth | 395 mm |
| Package height | 102 mm |
| Package weight | 2.59 kg |
| Package type | Box |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| UK Trade Tariff code | 85176200 |
| Country of origin | United Kingdom |
