Description
Lindy 4 Port HDMI 18G Splitter with Audio and Downscaling, HDMI, 4x HDMI, 4096 x 2160 pixels, Black, Metal, 4K Ultra HD
The Lindy 4 Port HDMI 2.0 18G Splitter with Audio is a multi-function solution for distributing high quality HDMI signals across 4 displays simultaneously from one source device, while extracting digital or analogue audio separately.
With support for resolutions up to 4K 60Hz 4:4:4 8bit, this splitter is great for creating eye-catching quad display digital signage in retail scenarios, displaying sports across multiple screens in sports bars or distributing engaging multiscreen educational presentations at tradeshows. The splitter also has separate optical and 3.5mm audio ports to easily extract audio from HDMI to connect non-HDMI amplifiers or soundbars, ideal for supporting video with immersive multichannel audio.
The splitters also feature an integrated switch to downscale the input signal to Full HD, making installations with older displays hassle free while always ensuring the viewer receives the optimum picture from their display.
Specifications
| Brand | LINDY |
|---|---|
| Manufacturer part no. | 38231 |
| Our part no. | 4R70505 |
| Category | Cables & Adapters › HDMI Cables & Extenders |
| Weight | 0 kg |
| Ports & interfaces | |
| Video port type | HDMI |
| Video out | 4x HDMI |
| HDMI version | 2.0 |
| Video ports quantity | 5 |
| Audio ports quantity | 2 |
| DC-in jack | Yes |
| Features | |
| Product colour | Black |
| Housing material | Metal |
| Maximum resolution | 4096 x 2160 pixels |
| HD type | 4K Ultra HD |
| Maximum refresh rate | 60 Hz |
| HDCP | Yes |
| LED indicators | Power |
| Power | |
| Output voltage | 5 V |
| Output current | 1 A |
| Weight & dimensions | |
| Width | 180 mm |
| Depth | 14.4 mm |
| Height | 63 mm |
| Packaging data | |
| Package width | 212 mm |
| Package depth | 55 mm |
| Package height | 148 mm |
| Package weight | 228 g |
| Package type | Box |
| Packaging content | |
| Manual | Yes |
| AC adapter included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
