Description

D-Link 8-Port Gigabit Unmanaged Desktop Switch, Unmanaged, L2, Gigabit Ethernet (10/100/1000), Full duplex

The DGS-1008D 8-Port Gigabit Desktop Switch is part of D-Link’s series of SOHO devices that allows you to easily expand and upgrade your network. D-Link’s Green Technology provides energy savings, reduces heat, and a longer product life without sacrificing performance or functionality. DGS-1008D provides eight Gigabit ports for easy expansion of your network and a quick way to upgrade your network to Gigabit connectivity. An energy-efficient power adapter (Energy Star Level V qualified), minimised use of harmful substances (RoHS compliant), and recyclable packaging make this switch truly environmentally friendly.

Fast and Reliable Networking

The D-Link DGS-1008D 8-Port Gigabit Desktop Switch creates a blazing fast network for your office, as its Gigabit Ethernet ports provide high-speed wired connections for up to eight PCs or other devices. The DGS-1008D also features QoS, which prioritises network traffic so that time-sensitive data is delivered efficiently, even during bursts of high data traffic. It’s stylish, easy-to-use, and comes IPv6-ready for a reliable network today and tomorrow.

Conserve Energy

The 8-Port Gigabit Desktop Switch helps you conserve energy automatically through several methods. It automatically powers down ports that have no link, allowing the switch to save a substantial amount of power by cutting power usage for unused ports. It also adjusts the amount of power supplied to a port according to the length of the connected Ethernet cable.

Environmentally-friendly

The 8-Port Gigabit Desktop Switch was designed with the environment in mind, and is compliant with Energy Star Level V, as well as with the stringent CEC and MEPS regulations that require the use of energy efficient power adapters. The switch is also built to follow RoHS standards to minimise the use of hazardous materials, and uses recyclable packaging that helps reduce waste, complying with the WEEE directive.

Specifications

BrandD-LINK
Manufacturer part no.DGS-1008D/B
Our part no.5841938
EAN0790069252730
CategoryNetworking › Unmanaged Switches
Weight0.2 kg
Management features
Switch typeUnmanaged
Switch layerL2
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Network
Full duplexYes
Data transmission
Switching capacity16 Gbit/s
MAC address table8000 entries
Maximum data transfer rate1 Gbit/s
Jumbo frames supportYes
Design
Rack mountingNo
SafetyCSA
Power
Power consumption (typical)4.5 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)No
Other features
Dimensions (WxDxH)192 x 118 x 30 mm
Connectivity technologyWired
I/O ports8 x 10/100/1000BASE-T
Power requirements7.5V 1A
Electromagnetic emissionsCE Mark, FCC Class B
Networking features10BASE-T, 100BASE-TX & 1000BASE- T
Power LEDNo
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-10 - 70 °C
Operating relative humidity (H-H)10 - 90%
Weight & dimensions
Weight300 g
Packaging data
Package width104 mm
Package depth158 mm
Package height94 mm
Package weight280 g
Technical details
Shipping (inner) case height19.3 cm
Shipping (inner) case width23 cm
Shipping (inner) case length49.8 cm
Shipping (inner) case net weight1.9 kg
Products per shipping (inner) case10 pc(s)
Pallet gross weight (air)350.2 kg
Master (outer) cases per pallet (air)100 pc(s)
Products per pallet (air)1000 pc(s)
Pallet gross length110 cm
Pallet gross width120 cm
Pallet height (air)2.06 m
Pallet gross weight (sea)350.2 kg
Master (outer) cases per pallet (sea)100 pc(s)
Products per pallet (sea)1000 pc(s)
Pallet height (sea)2.06 m
Shipping (inner) case gross weight3.32 kg
Logistics data
Harmonized System (HS) code85176990
