Description
Zyxel XGS1930-28HP, Managed, L3, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting
The most affordable choice for 10G migration The XGS1930 series, a new 10G uplink smart managed switch, comes with a stylish new look and enables cloud manageability with Zyxel NebulaFlexTM technology.
Built for convenience This smart-looking switch features an intuitive design that simplifies daily network management for SMBs.
Manage it your way! The XGS1930 series introduces Zyxel NebulaFlexTM, which allows you to easily switch between standalone mode and our license-free Nebula cloud management platform anytime with just a few simple clicks.
Don’t overspend to upgrade your wired network With Gigabit connectivity plus four 10G uplinks, the XGS1930 series is ideal for those seeking to upgrade to an easier-to-manage network—and at an affordable price.
Whisper-quiet operation Smart fan and fanless designs for silent operation in your workplace.
Power more devices more easily - Provides 30W per port and a high power budget of 375W, ideal for denser PoE deployments. - Default consumption mode boosts efficiency by delivering the actual power required.
User-friendly LED indicators View real-time status instantly with cloud and PoE power-usage LED indicators.
Zyxel ONE Network Use the complimentary ZON Utility to configure and discover switches, WLANs, and gateways in your network with one click.
Designed for the long haul A web smart managed switch with an enterprise-grade hardware design. Built-in state-of-the-art hardware technology brings high quality and robustness to SMB networks.
Specifications
| Brand | ZYXEL |
|---|---|
| Manufacturer part no. | XGS1930-28HP-GB0101F |
| Our part no. | B776198 |
| EAN | 4718937595013 |
| Category | Networking › Unmanaged Switches |
| Weight | 5.7 kg |
| Management features | |
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP+ module slots quantity | 4 |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Port mirroring | Yes |
| IP routing | Yes |
| Routing entries | 32 |
| Flow control support | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Virtual LAN features | Port-based VLAN, Voice VLAN |
| Number of VLANs | 4000 |
| Data transmission | |
| Switching capacity | 128 Gbit/s |
| Forwarding rate | 95.2 Mpps |
| MAC address table | 16000 entries |
| Static route | Yes |
| Packet buffer memory | 1.5 MB |
| Security | |
| DHCP features | DHCP client, DHCP relay, DHCPv6 relay |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| SSH/SSL support | Yes |
| Loop protection | Yes |
| Authentication | Guest VLAN, MAC-based authentication, Port-based authentication |
| Password protection | Yes |
| Multicast features | |
| Multicast support | Yes |
| Protocols | |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Design | |
| Rack mounting | Yes |
| Product colour | Black |
| Electromagnetic compatibility | FCC 15 A, CE A, BSMI EMC |
| Performance | |
| Internal memory | 512 MB |
| Flash memory | 32 MB |
| Noise level | 28.5 dB |
| Mean time between failures (MTBF) | 1369432 h |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 471 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 24 |
| Total Power over Ethernet (PoE) budget | 375 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Storage relative humidity (H-H) | 10 - 95% |
| Heat dissipation | 1606.11 BTU/h |
| Weight & dimensions | |
| Width | 441 mm |
| Depth | 330 mm |
| Height | 44 mm |
| Weight | 4.6 kg |
| Packaging content | |
| Cables included | AC |
| Rack mount kit | Yes |
| Packaging data | |
| Package type | Box |
| Package width | 585 mm |
| Package depth | 503 mm |
| Package height | 95 mm |
| Package weight | 5.82 kg |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
