Description

StarTech.com 6ft (2m) VESA Certified Mini DisplayPort to DisplayPort 1.4 Cable - 8K 60Hz HBR3 HDR - Super UHD mDP to DP 1.4 Cord - Slim (34 AWG) Ultra HD 4K 120Hz - Monitor/Video Cable, 2 m, DisplayPort, Mini DisplayPort, Male, Male, 7680 x 4320 pixels

mDP to DP Cable | DP 1.4 | 8K@60Hz | VESA® Certified | Lifetime Warranty

This 2 meter VESA Certified Mini DisplayPort to DisplayPort v1.4 cable features a mDP male connector on one end, and a DP male latching connector on the other, allowing you to connect any Mini DisplayPort-enabled laptop or workstation to an 8K TV, monitor or projector that uses a standard DisplayPort connection.

Astonishing Picture Quality

This mDP to DP 1.4 cable supports high resolutions of up to 8K (7680 x 4320p) at 60Hz or 4K (3840 x 2160) at 120Hz with a maximum HBR3 bandwidth of 32.4 Gbps and ensures that digitally protected content is displayed properly, with both HDCP 2.2 and DPCP capability. The adapter cable also supports:

• Multi-Stream Transport (MST) for daisy chaining multiple monitors. • Display Stream Compression (DSC) v1.2 transport that enables up to 3:1 compression ratio. • HDR meta transport, which offers a flexible metadata packet transport to support future dynamic HDR standards. • Expanded audio transport, which covers capabilities such as 32 uncompressed audio channels, 1536kHz sample rate. • Forward Error Correction (FEC), which overlays the DSC 1.2 transport, addresses the transport error resiliency needed for compressed video transport to external displays.

Ultimate Compatibility

This Mini DisplayPort to DisplayPort adapter is compatible with several systems, including your PC, Mac and Microsoft Surface devices with mDP. For ultimate convenience, this Mini DisplayPort cable works with computers that are equipped with Thunderbolt 2 ports, enabling you to connect your DP compatible displays to your mDP source. In addition, this DP1.4 adapter cable supports a wide selection of mDP1.4-equipped graphics cards such as:

• Radeon™ VII, SSG, WX x100, Pro and FirePro™ series. • Nvidia Quadro P series.

Built to Last

This Mini DisplayPort to DisplayPort v1.4 adapter cable is designed with gold-plated latching DisplayPort connectors that prevent accidental disconnection, making it a great accessory for office or boardroom applications.

Having 34 AWG conductors and 4.5mm outer diameter, this slim cable offers both flexibility and ease of connection.

The DP14MDPMM2MB is backed by a StarTech.com lifetime warranty and free lifetime technical support.

Specifications

BrandSTARTECH
Manufacturer part no.DP14MDPMM2MB
Our part no.CB40386
EAN0065030892032
CategoryCables & Adapters › VGA & Video Adapters
Weight0 kg
Features
Connector 1 form factorStraight
Connector 2 form factorStraight
Connector contacts platingGold
DisplayPort version1.4
Maximum resolution7680 x 4320 pixels
Maximum refresh rate120 Hz
HDCPYes
Cable length2 m
Connector 1DisplayPort
Connector 2Mini DisplayPort
Connector 1 genderMale
Connector 2 genderMale
Product colourBlack
Cable shieldingAluminum mylar foil
Jacket materialPolyvinyl chloride (PVC)
AWG wire size34
HBR3 supportYes
Multi-Stream Transport (MST)Yes
Number of conductors19
Operational conditions
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)0 - 85%
Certificates
Compliance certificatesCE, RoHS
Weight & dimensions
Cable diameter4.5 mm
Weight85 g
Packaging data
Package width198 mm
Package depth172 mm
Package height17 mm
Package weight90 g
Packaging content
Quantity per pack1 pc(s)
Logistics data
Harmonized System (HS) code84733080
Master (outer) case width410 mm
Master (outer) case length341 mm
Master (outer) case height276 mm
Products per master (outer) case80 pc(s)
