Description
Vertiv EDGELI-3000IRT2U, Line-Interactive, 3 kVA, 2700 W, Sine, 166 V, 278 V
The Vertiv Edge Lithium Ion uninterruptible power supply (UPS) is designed to safeguard critical equipment in server rooms, network closets and other edge and distributed IT applications. This 3 kVA UPS offers lower total cost of ownership, which can be up to 50% savings over lifetime. Lithium-ion batteries have greater power density, last about 2-3 times as long, recharge quicker and endure up to x10 more discharge cycles than traditional valve-regulated-lead-acid (VLRA) batteries. It includes automatic voltage regulation (AVR) technology to further extend battery life and provides plenty of runtime on battery during an outage for an orderly shutdown. This set-it-and-forget-it single phase UPS system comes with a five-year standard warranty for UPS and batteries, and together with the optional webcard for remote management, becomes ideal for remote or unmanned locations. This rack/tower UPS comes with a rotating LCD display to allow both rack and tower configurations.
Specifications
| Brand | VERTIV |
|---|---|
| Manufacturer part no. | EDGELI-3000IRT2U |
| Our part no. | CD12849 |
| EAN | 0767041033823 |
| Category | Power & UPS › UPS |
| Weight | 34 kg |
| Features | |
| UPS topology | Line-Interactive |
| Output power capacity | 3 kVA |
| Output power | 2700 W |
| Waveform | Sine |
| Input operation voltage (min) | 166 V |
| Input operation voltage (max) | 278 V |
| Input frequency | 45/65 Hz |
| Output operation voltage (max) | 240 V |
| Automatic Voltage Regulation (AVR) | Yes |
| Maximum current | 10 A |
| Surge energy rating | 624 J |
| Response time | 6 ms |
| Efficiency | 98.5% |
| Power factor | 0.9 |
| Input power factor | 0.9 |
| Output power factor | 0.9 |
| Emergency Power Off (EPO) | Yes |
| EMI/RFI noise filtering | Yes |
| Noise level | 55 dB |
| Audible alarm(s) | Yes |
| Ports & interfaces | |
| AC outlet types | C13 coupler, C19 coupler |
| AC outlets quantity | 6 AC outlet(s) |
| USB port | Yes |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Typical backup time at full load | 10.5 min |
| Typical backup time at half load | 22.6 min |
| Battery life (max) | 5 year(s) |
| Hot-swap battery | Yes |
| Design | |
| Form factor | Rackmount |
| Rack capacity | 2U |
| Product colour | Black |
| Display type | LCD |
| LED indicators | Diagnostic |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -10 - 45 °C |
| Operating relative humidity (H-H) | 8 - 90% |
| Operating altitude | 0 - 3000 m |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | CE, EAC, RCM, CB report, ISTA 2A, UN38.3 |
| Packaging content | |
| Cables included | Output power cable, USB cable, Input power cable |
| Weight & dimensions | |
| Width | 438 mm |
| Depth | 630 mm |
| Height | 86 mm |
| Weight | 24.3 kg |
| Packaging data | |
| Package width | 600 mm |
| Package depth | 800 mm |
| Package height | 240 mm |
| Package weight | 32.1 kg |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Country of origin | China |
