Description
Neomounts WL40-540BL14 TV mount wall 32-55" - full motion - easy install, 100 x 100 mm, 400 x 400 mm, -2 - 12°, 0 - 30°, Steel, Black
The Neomounts WL40-540BL14 LEVEL is a full motion wall mount for flat screens up to 55" with a maximum weight capacity of 35 kg. The versatile tilt (14°) and swivel (30°) technology allows you to create the optimum viewing angle. The mount can be levelled for the perfect installation.
The LEVEL-550 wall mount has a depth of 4,6-30,8 cm and is suitable for screens that meet VESA hole pattern 100x100 to 400x400 mm.
The WL40-540BL14 features a nifty Easy-release system, that allows you to attach the TV in a wink of an eye. The mount is equipped with cable management, to secure any loose cables on the back of the screen.
Specifications
| Brand | NEOMOUNTS |
|---|---|
| Manufacturer part no. | WL40-540BL14 |
| Our part no. | CE00814 |
| EAN | 8717371448721 |
| Category | Monitors & Displays › Monitor Mounts & Stands |
| Weight | 3.4 kg |
| Mounting | |
| Maximum weight capacity | 35 kg |
| Minimum screen size | 81.3 cm (32") |
| Number of displays supported | 1 |
| Maximum weight capacity (per display) | 35 kg |
| Maximum screen size | 139.7 cm (55") |
| Minimum VESA mount | 100 x 100 mm |
| Maximum VESA mount | 400 x 400 mm |
| Panel mounting interface | 100 x 100,200 x 100,200 x 200,200 x 300,200 x 400,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400 |
| Mounting type | Wall |
| Ergonomics | |
| Height adjustment | No |
| Tilt adjustment | Yes |
| Tilt angle range | -2 - 12° |
| Swivelling | Yes |
| Swivel angle | 30° |
| Swivel angle range | 0 - 30° |
| Rotating | Yes |
| Angle of rotation | 6° |
| Pivot angle | -3 - 3° |
| Cable management | Yes |
| Type | Full motion |
| Distance to the wall (max) | 30.8 cm |
| Distance to the wall (min) | 4.6 cm |
| Design | |
| Product colour | Black |
| Housing material | Steel |
| Technical details | |
| Country of origin | China |
| Package net weight | 3.7 kg |
| Quantity per pack | 1 pc(s) |
| Lockable | Not lockable |
| Packaging content | |
| Mounting kit | Yes |
| Weight & dimensions | |
| Width | 433 mm |
| Depth | 46 mm |
| Depth (max) | 4.6 cm |
| Height | 433 mm |
| Weight | 2.7 kg |
| Packaging data | |
| Package width | 442 mm |
| Package depth | 229 mm |
| Package height | 56 mm |
| Package weight | 3.7 kg |
| Logistics data | |
| Master (outer) case width | 462 mm |
| Master (outer) case length | 300 mm |
| Master (outer) case height | 250 mm |
| Master (outer) case gross weight | 19 kg |
| Master (outer) case net weight | 17.5 kg |
| Products per master (outer) case | 5 pc(s) |
| Harmonized System (HS) code | 7326909890 |
| Products per pallet (EU) | 150 pc(s) |
