Description
Neomounts WL70-550BL14 Monitor/TV mount wall 40-55" - gas spring - full motion, 75 x 75 mm, 400 x 400 mm, -15 - 5°, 0 - 180°, 6°, Black
The Neomounts WL70-550BL14 is a full motion wall mount for flat screens up to 55" with a maximum weight capacity of 30 kg. The versatile tilt (20°) and swivel (180°) technology allows you to create the optimum viewing angle. The mount can be levelled for the perfect installation.
The WL70-550BL14 has a depth of 6,1-56,5 cm and is suitable for screens that meet VESA hole pattern 75x75 to 400x400 mm.
The mount can be easily adjusted in height using the gas spring. The cable management system allows you to route and secure any loose cables at the back of the screen. Additionally, the mount features an Easy-release VESA, that allows you to attach the TV in a wink of an eye.
Specifications
| Brand | NEOMOUNTS |
|---|---|
| Manufacturer part no. | WL70-550BL14 |
| Our part no. | CE16617 |
| EAN | 8717371449063 |
| Category | Monitors & Displays › Monitor Mounts & Stands |
| Weight | 5.3 kg |
| Mounting | |
| Maximum weight capacity | 30 kg |
| Minimum screen size | 101.6 cm (40") |
| Number of displays supported | 1 |
| Maximum weight capacity (per display) | 30 kg |
| Maximum screen size | 139.7 cm (55") |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 400 x 400 mm |
| Panel mounting interface | 100 x 100,200 x 100,200 x 200,300 x 300,400 x 200,400 x 300,400 x 400,75 x 75 |
| Mounting type | Wall |
| Ergonomics | |
| Height adjustment | Yes |
| Height adjustment type | Gas spring |
| Height adjustment range | 45 - 327 mm |
| Tilt adjustment | Yes |
| Tilt angle range | -15 - 5° |
| Swivelling | Yes |
| Swivel angle | 180° |
| Swivel angle range | 0 - 180° |
| Rotating | Yes |
| Angle of rotation | 6° |
| Pivot angle | -3 - 3° |
| Cable management | Yes |
| Distance to the wall (max) | 56.5 cm |
| Distance to the wall (min) | 6.1 cm |
| Design | |
| Product colour | Black |
| Housing material | Steel |
| Technical details | |
| Country of origin | China |
| Package net weight | 5.5 kg |
| Quantity per pack | 1 pc(s) |
| Weight & dimensions | |
| Width | 450 mm |
| Depth | 565 mm |
| Depth (max) | 56.5 cm |
| Height | 450 mm |
| Weight | 4.53 kg |
| Packaging data | |
| Package width | 365 mm |
| Package depth | 505 mm |
| Package height | 75 mm |
| Package weight | 5.5 kg |
| Logistics data | |
| Master (outer) case width | 380 mm |
| Master (outer) case length | 520 mm |
| Master (outer) case height | 345 mm |
| Master (outer) case gross weight | 17.5 kg |
| Master (outer) case net weight | 13.8 kg |
| Products per master (outer) case | 3 pc(s) |
| Harmonized System (HS) code | 7326909890 |
| Products per pallet (EU) | 72 pc(s) |
| Other features | |
| Mounting | Screws |
| Minimum weight | 5 kg |
