Description

StarTech.com USB-C to Dual HDMI Adapter, USB Type-C Multi-Monitor MST Hub, Dual 4K 60Hz HDMI Laptop Display Extender / Splitter, HDR, Extra-Long Built-In Cable - Windows Only, USB Type-C, HDMI output, DisplayPort output, 3840 x 2160 pixels

Create a high-performance dual-display workstation by connecting a USB Type-C™ device to two independent HDMI® monitors

This USB-C to HDMI MST Hub allows you to connect two HDMI monitors, using a USB-C enabled host device.

Multi-tasking Made Easy

This USB-C to HDMI video splitter connects up to two additional displays in extended or mirror mode. Connecting two independent 4K 60Hz displays creates high-performance workstations, for users in your organization enabling easier multi-tasking resulting in increased productivity.

Multi-Stream Transport (MST) technology combines multiple video signals into a single signal/stream. This MST Hub separates the single stream into two independent signals, one for each HDMI enabled display. Support for High Dynamic Range (HDR) offers increased contrast, brightness, colors, and greater luminosity.

Hassle-Free Setup

Windows devices that support DP Alt Mode over USB-C feature native support for MST. This USB-C to HDMI hub is compatible with Thunderbolt 4, Thunderbolt 3, and USB4 enabled Windows devices. Plug-and-play installation with no drivers or software required. The 12in (30cm) attached cable provides options for flexible installation configurations, reducing the amount of strain on ports and connectors. Additionally, this dual-monitor splitter is bus-powered, meaning no external power is required.

MST14CD122HD is backed by a StarTech.com 3-year warranty, and free lifetime multilingual, North American based technical support.

Specifications

BrandSTARTECH
Manufacturer part no.MST14CD122HD
Our part no.CE54575
EAN0065030888288
CategoryCables & Adapters › HDMI Cables & Extenders
Weight0.1 kg
Performance
USB connector typeUSB Type-C
USB connector genderMale
USB connector form factorStraight
DVI outputNo
High Dynamic Range (HDR) supportedYes
HDMI outputYes
DisplayPort outputYes
Number of displays supported2
HDMI ports quantity2
Maximum resolution3840 x 2160 pixels
Refresh rate at maximum resolution60 Hz
Audio output channels7.1 channels
ChipsetSynaptics VMM5200
Data transfer rate (max)32.4 Gbit/s
Design
Product colourBlack, Grey
Housing materialPlastic
Integrated USB cableYes
System requirements
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 x64, Windows 11, Windows 11 x64
Weight & dimensions
Width105 mm
Depth43 mm
Height14 mm
Weight55 g
USB cable length0.3 m
Operational conditions
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)5 - 90%
Packaging data
Package width142 mm
Package depth170 mm
Package height30 mm
Package weight108.8 g
Technical details
Compliance certificatesCE, RoHS
Logistics data
Products per master (outer) case70 pc(s)
Master (outer) case width460 mm
Master (outer) case length331 mm
Master (outer) case height440 mm
Harmonized System (HS) code84733020
