Description
Origin Storage E1MG-BXU Brocade Compatible Transceiver SFP 1000Base-BX-U (Tx1310nm/Rx1490nm 10km SMF DOM), Fiber optic, 1000 Mbit/s, SFP, LC, 10000 m, 1490 nm
1000Base-BXU SFP Optic SMF 1310nm / 1490nm 10KM Brocade Compatible
Specifications
| Brand | ORIGIN STORAGE |
|---|---|
| Manufacturer part no. | E1MG-BXU-OS |
| Our part no. | CF41309 |
| EAN | 5059902013927 |
| Category | Networking › Transceivers & SFPs |
| Weight | 0 kg |
| Performance | |
| SFP transceiver type | Fiber optic |
| Maximum data transfer rate | 1000 Mbit/s |
| Interface type | SFP |
| Single-mode fiber (SMF) supported | Yes |
| Multi-mode fiber (MMF) supported | No |
| Fiber optic connector | LC |
| Maximum transfer distance | 10000 m |
| Wavelength | 1490 nm |
| Tx wavelength (max) | 1310 nm |
| Rx wavelength (max) | 1490 nm |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Digital Diagnostics Monitoring (DDM) | Yes |
| Features | |
| Product colour | Silver |
| Housing material | Metal |
| Plug and Play | Yes |
| Hot-Plug support | Yes |
| Hot-swap | Yes |
| Easy to install | Yes |
| Brand compatibility | Brocade |
| Power | |
| Input voltage | 3.3 V |
| Certificates | |
| Compliance certificates | Electromagnetic Compatibility (EMC), REACH, RoHS, CE, Federal Communications Commission (FCC) |
| Certification | CE, FCC, RoHS, REACH |
| Sustainability | |
| Doesn't contain | Lead |
| Operational conditions | |
| Minimum operating temperature | 0 °C |
| Maximum operating temperature | 70 °C |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Storage relative humidity (H-H) | 0 - 85% |
| Packaging data | |
| Package type | Blister |
| Logistics data | |
| Warranty period | 20 year(s) |
| Country of origin | Taiwan, China |
