Description

Viewsonic PS502W, 4000 ANSI lumens, WXGA (1280x800), 15000:1, 1524 - 7620 mm (60 - 300"), 0.67 - 3.36 m, 1.07 billion colours

The PS502W is ViewSonic’s high brightness WXGA short throw business/education projector. Boasting 4,000 ANSI Lumens of high brightness, the projector offers clear images of up-to-300” large screen in meeting rooms, classrooms, or any other bright environment. With 0.52 short throw ratio, the projector can provide 100” large screen size from only 1.1 m away without being obstructed by shadows, allowing for a large screen even in small spaces. The dual HDMI ports allow you to flexibly connect to multiple devices, easily switching between content sources. The USB Type-A port can supply power to HDMI wireless dongles, making wireless content streaming more convenient. The projector also allows software updates via USB cable connection with simply your laptops, skipping trips to service centers. ​

High Brightness for Business & Education Environments​ Thanks to 4,000 ANSI Lumens brightness, you're guaranteed clear visuals of vibrancy, which are perfectly suitable for spaces with a lot of ambient light.

Big Screen for Small Spaces The PS502W’s 0.52 short throw projection gives you 100” from only 1.3m away when positioning the projector. Presenters will stay clear of the projector beam, eliminating eye glare and shadows on the projection screen.

Ultra-Large Screen with Lower Cost-per-inch​​ The projector allows for an up-to-300” image size, which is much larger and easier to install than commercial displays.

Easy and Flexible Connection​ The dual HDMI ports offer ample connectivity to accommodate all your HDMI-enabled multimedia devices. You no longer have to unplug your existing device to switch to a new one. Simply use the on-screen display to select and change the input source.​

Vibrant Colors for Captivating Presentations Impress any audience with ViewSonic’s exclusive color technology and elevate your presentation with a true-to-life color experience.

A Simpler Way to Update Projector Software​ Skip trips to the service center by keeping software up to date easily and onsite via USB cable connection with your laptop.​​​

​​​*The latest projector software update can be found in the download section at the bottom of the page when available.​

USB Type A Power Supply​ A built-in 5V/1.5A USB power output can be used to supply power to HDMI wireless dongles, eliminating the need for separate power adapters when streaming your multimedia content.

Audio Right Out of the Box The projector comes equipped with a 16W speaker, allowing for audio to be delivered during presentations without the need for external speakers.

Specifications

BrandVIEWSONIC
Manufacturer part no.PS502W
Our part no.CH01963
EAN0766907020038
CategoryProjectors › Other (1302)
Weight4.3 kg
Projector
Smart projectorNo
Screen size compatibility1524 - 7620 mm (60 - 300")
Projection distance0.67 - 3.36 m
Projector brightness4000 ANSI lumens
Projector native resolutionWXGA (1280x800)
Contrast ratio (typical)15000:1
Number of colours1.07 billion colours
Horizontal scan range15 - 102 kHz
Vertical scan range23 - 120 Hz
Keystone correction, vertical-19 - 19°
Light source
Light source typeLamp
Service life of light source4000 h
Service life of light source (economic mode)12000 h
Lamp typeUHP
Lamp power240 W
Lamps quantity1 lamp(s)
Lens system
FocusManual
Fixed focal length7.51 mm
F-number (relative aperture)2.8
Zoom capabilityYes
Digital zoom2x
Throw ratio0.52
Offset112.4%
Video
Analog signal format systemNTSC, PAL, SECAM
Full HDYes
3DNo
Supported graphics resolutions640 x 480 (VGA), 1920 x 1080 (HD 1080)
Supported video modes480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Ports & interfaces
HDMI connector typeFull-size
HDMI version1.4
Service port typeUSB Type-A
USB 2.0 ports quantity1
USB 2.0 Type-A ports quantity1
Serial interface typeRS-232
PC Audio inYes
PC Audio outYes
PC in (D-Sub)Yes
VGA (D-Sub) ports quantity2
HDMI ports quantity2
DVI portNo
AC (power) inYes
Network
Smart TVNo
Ethernet LANNo
Wi-FiNo
Storage
Card reader integratedNo
Features
InteractiveNo
Noise level (economic mode)25 dB
HDCPYes
On Screen Display (OSD)Yes
On Screen Display (OSD) languagesArabic, Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Indonesian, Italian, Korean, Polish, Portuguese, Russian, Thai, Turkish, Vietnamese
Number of OSD languages22
HDCP version1.4
Noise level34 dB
Air filterYes
Multimedia
Built-in speaker(s)Yes
RMS rated power16 W
Design
Market positioningEducation
Product typeShort throw projector
Product colourWhite
LED indicatorsYes
Cable lock slotYes
Cable lock slot typeKensington
Display
Built-in displayNo
Power
Power sourceAC
Power consumption (typical)295 W
Power consumption (standby)0.5 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Operational conditions
Operating temperature (T-T)0 - 40 °C
Weight & dimensions
Width309 mm
Depth234 mm
Height115 mm
Weight2.9 kg
Package width400 mm
Package depth168 mm
Package height337 mm
Package weight4.1 kg
Packaging content
Remote control includedYes
Remote control typeIR
Cables includedAC, VGA
Quick start guideYes
Warranty cardYes
Technical details
Image lag time33.2 ms
Logistics data
Pallet gross length102 cm
Pallet gross width122 cm
Pallet gross height181.5 cm
Products per master (outer) case1 pc(s)
Harmonized System (HS) code8528620000
