Description
D-Link DMS-3130-30PS, Managed, L3, 10G Ethernet (100/1000/10000), Power over Ethernet (PoE)
Specifications
| Brand | D-LINK |
|---|---|
| Manufacturer part no. | DMS-3130-30PS/E |
| Our part no. | CI01033 |
| EAN | 0790069467172 |
| Category | Networking › Managed Switches |
| Weight | 10 kg |
| Management features | |
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| System event log | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 2 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| 10G Ethernet (copper) ports quantity | 2 |
| SFP module slots quantity | 24 |
| Console port | RJ-45 |
| USB 2.0 ports quantity | 1 |
| Power connector | AC-in jack |
| Network | |
| Networking standards | IEEE 802.11ad, IEEE 802.1ag, IEEE 802.3ah, IEEE 802.1p, IEEE 802.11d, IEEE 802.1s, IEEE 802.1AX, IEEE 802.3x, IEEE 802.1v, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x |
| 10G support | Yes |
| Port mirroring | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| Ethernet Ring Protection Switching (ERPS) | Yes |
| Fast leave | Yes |
| VLAN support | Yes |
| Virtual LAN features | Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN, Voice VLAN, Multicast VLAN, Private VLAN |
| Number of VLANs | 4000 |
| Data transmission | |
| Switching capacity | 400 Gbit/s |
| Forwarding rate | 298 Mpps |
| MAC address table | 32768 entries |
| Number of queues | 8 |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Packet buffer memory | 4 MB |
| Security | |
| DHCP features | DHCP client, DHCP relay, DHCP server, DHCP snooping |
| Access Control List (ACL) | Yes |
| Access Control List (ACL) egress | 512 |
| Access Control List (ACL) ingress | 2048 |
| IGMP snooping | Yes |
| IGMP entries | 1024 |
| Static port security | Yes |
| SSH/SSL support | Yes |
| Loop protection | Yes |
| BPDU filtering/protection | Yes |
| Authentication | Guest VLAN |
| Root protection | Yes |
| DoS attack prevention | Yes |
| Authentication type | RADIUS, TACACS+ |
| Queue scheduling algorithms | Weighted Round Robin (WRR), Weighted random early detection (WRED), Strict Priority Queue (SPQ) |
| Packet filtering | L3 |
| Multicast features | |
| Multicast support | Yes |
| MLD entries | 64 |
| Protocols | |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Routing protocols | OSPFv2, RIPng, OSPFv3, RIP-1, RIP-2 |
| Design | |
| Stackable | Yes |
| Product colour | Black |
| Number of fans | 3 fan(s) |
| Safety | CB, cUL, BSMI, CCC |
| Performance | |
| Physical stacking (units) | 9 |
| Virtual stacking (units) | 32 |
| Noise level | 54 dB |
| sFlow | Yes |
| Mean time between failures (MTBF) | 487153 h |
| Power | |
| Power source | AC |
| Power supply included | Yes |
| Redundant power supply (RPS) support | Yes |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 1211.5 W |
| Surge protection | Yes |
| Surge protection voltage | 6 kV |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 16 |
| Power over Ethernet (PoE) power per port | 60 W |
| Total Power over Ethernet (PoE) budget | 960 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 413.73 BTU/h |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 250 mm |
| Height | 250 mm |
| Weight | 6.54 kg |
| Certificates | |
| Certification | FCC Class A, CE Class A, VCCI Class A, IC, RCM, BSMI, CCC |
