Description

Lindy DST-Pro USB4, USB-C Laptop Docking Station, Docking, USB4, 100 W, 3.5 mm, 1000 Mbit/s, Anthracite

The DST-Pro USB4 of the latest USB4 generation is a high performance, multifunctional solution for connecting laptops, tablets or mobile phones to a range of interfaces including an 8K 30Hz DisplayPort or HDMI display or two displays simultaneously at 4K 60Hz*, using a single cable. It also supports video resolutions of 4K 120Hz, making it the ideal tool for high resolution video editing or game streaming.

This docking station delivers a whole host of capable ports to connect your devices into your workflow. With SuperSpeed USB and Ethernet, you can expect to have a blazing fast experience and improve your productivity whilst the Card Readers (SD and Micro-SD) allow you to expand your storage capacity beyond that of your device. Through a single USB-C cable, connect to multiple SuperSpeed 10Gbps USB Type A or Type C ports, a 3.5mm combined headphone jack, Gigabit Ethernet, (Micro-) SD card slots, DisplayPort and HDMI.

The USB4 Docking Station also supports Power Delivery 3.0 up to 100W for charging the connected laptop. A power supply is not included. The dock can be used with the power supply supplied with the laptop or a power supply can be purchased separately.

This USB4 Laptop Docking Station is compatible with computers featuring the USB Type C port with support for DisplayPort 1.4 Alternate Mode, i.e. USB4 or USB 3.2 as well as Thunderbolt 3 or TB4 host devices.

*Please note that macOS does not support MST.

Specifications

BrandLINDY
Manufacturer part no.43372
Our part no.CI11247
CategoryCables & Adapters › USB Cables & Adapters
Weight0 kg
Ports & interfaces
Connectivity technologyDocking
Host interfaceUSB4
USB 2.0 ports quantity3
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
USB4 ports quantity1
PowerShareYes
Number of USB ports with PowerShare support3
USB Power Delivery (USB PD)Yes
USB Power Delivery revision3.0
USB Power Delivery up to100 W
HDMI ports quantity1
HDMI version2.1
DisplayPorts quantity1
DisplayPort version1.4
Microphone inYes
Combo headphone/mic portYes
Headphone outputs1
Headphone connectivity3.5 mm
HDCPYes
HDCP version2.2
USB Type-C DisplayPort Alternate ModeYes
Network
Ethernet LANYes
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates1000 Mbit/s
Performance
Card reader integratedYes
Compatible memory cardsMicroSD (TransFlash), SD
Data transfer rate1 Gbit/s
Maximum digital resolution7680 x 4320 pixels
Number of displays supported2
Maximum refresh rate120 Hz
Product colourAnthracite
Housing materialAluminium
Power
Power source typeUSB
Power consumption (max)20 W
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-10 - 70 °C
Operating relative humidity (H-H)10 - 90%
Sustainability
Sustainability complianceYes
Weight & dimensions
Width129 mm
Depth69.5 mm
Height48 mm
Weight300 g
Packaging data
Package width174 mm
Package depth151 mm
Package height56 mm
Package weight400 g
Packaging content
Cables includedUSB Type-C to USB Type-C
ManualYes
Technical details
Compliance certificatesCE, Federal Communications Commission (FCC), REACH, RoHS
