Description

StarTech.com 3ft (1m) USB4 Cable 40Gbps, 100W (5A) Power Delivery, 8K 120Hz / 4K 240Hz DP Alt Mode, USB-IF Certified USB-C Cable - Thunderbolt Compatible, 1 m, USB C, USB C, USB4 Gen 2x2, 40 Gbit/s

Connect to USB4-enabled devices, using this USB-IF certified USB-C cable

This 3ft (1m) USB4 Cable connects to USB Type-C® (USB 3.2), Thunderbolt™ 4/3, and PCIe-enabled devices, delivering up to 40Gbps, 4K/8K video, and 100W charging.

Establish Fast and Stable Power/Data Connections

This USB4 Type-C cable is USB-IF certified for guaranteed USB-C compatibility. It reliably delivers consistent transfer rates and up to 100W PD output. It is ideal for 40Gbps data transfer to external USB-C-enabled external storage devices or as a single-cable connection from a USB-C dock to a laptop.

This cable has undergone rigorous USB-IF compliance testing to meet USB4 specifications. This includes electrical and mechanical standards which ensures a reliable, high-quality cable for USB-C devices.

Experience 8K Video with DisplayPort 2.1 Alt Mode

The USB4 cable supports up to 8K 120Hz or 4K 240Hz video over DisplayPort 2.1 Alt Mode with DSC, HDR, and HBR3, and is compatible with dual 4K 60Hz and lower resolutions.

Power a USB-C Laptop

Power and charge a USB-C laptop, such as Apple MacBook, Lenovo ThinkPad, or Microsoft Surface with up to 100W output over USB Power Delivery 3.0. Connect the USB4 cable from a laptop to a USB-C wall charger or docking station.

Specifications

BrandSTARTECH
Manufacturer part no.CC1M-40G-USB-CABLE
Our part no.CI43284
EAN0065030897068
CategoryCables & Adapters › USB Cables & Adapters
Weight0 kg
Features
USB versionUSB4 Gen 2x2
Connector 1USB C
Connector 2USB C
Connector 1 genderMale
Connector 2 genderMale
Connector 1 form factorStraight
Connector 2 form factorStraight
AWG wire size34
Connector contacts platingNickel
Cable jacket materialThermoplastic elastomer (TPE)
Maximum data transfer rate40000 Mbit/s
Maximum data transfer rate40 Gbit/s
Cable typeRound cable
USB Power Delivery (USB PD)Yes
USB Power Delivery up to100 W
USB Type-C DisplayPort Alternate ModeYes
Maximum resolution7680 x 4320 pixels
Maximum refresh rate120 Hz
Display Stream Compression (DSC)Yes
High Dynamic Range (HDR) supportedYes
Weight & dimensions
Cable length1 m
Cable diameter5 mm
Weight53 g
Packaging data
Package width126 mm
Package depth187 mm
Package height14 mm
Package weight30 g
Packaging content
Quantity per pack1 pc(s)
Sustainability
Sustainability complianceYes
Doesn't containHalogen
Operational conditions
Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-10 - 70 °C
Certificates
Compliance certificatesRoHS
Logistics data
Products per master (outer) case180 pc(s)
Master (outer) case width517 mm
Master (outer) case length329 mm
Master (outer) case height226 mm
