Description

Lindy 4 Port USB 3.0 Metal Hub, USB 3.2 Gen 1 (3.1 Gen 1) Type-B, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, 5000 Mbit/s, Black, Metal, Round cable

The Lindy 4 Port USB 3.0 Metal Hub has been designed to provide reliable performance in demanding operational environments. This industrial-grade hub features a rugged, all-metal chassis providing excellent EMC protection. With robust metal housing and integrated mounting brackets this Hub is the ideal solution for use in industrial environments.

Backwards compatibility with USB 2.0/1.1/1.0 means the hub can simultaneously support older USB peripherals or systems that lack USB 3.0 capabilities, extending their lifetime and giving a greater return on investment. The hub also supports MTT technology which guarantees highest possible throughput speed for USB 1.1 devices.

Each port features individual short circuit protection, while the included power supply ensures secure and uninterrupted electricity supply.

Information about USB 3.0, 3.1 and 3.2

USB 3.0, USB 3.1 and USB 3.2 PCs, cables and devices are all compatible with each other, when using either a USB Type A or USB Type C host interface.

USB 3.0, USB 3.1 Gen 1 and USB 3.2 Gen 1 all support data transfer rates up to 5 Gbps.

USB 3.1 Gen 2 and USB 3.2 Gen 2 both support data transfer rates up to 10 Gbps.

Specifications

BrandLINDY
Manufacturer part no.43374
Our part no.CI68697
EAN4002888433747
CategoryCables & Adapters › USB Cables & Adapters
Weight0.6 kg
Ports & interfaces
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-B
Hub interfacesUSB 3.2 Gen 1 (3.1 Gen 1) Type-A
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Ports quantity4
Card reader integratedNo
DC-in jackYes
Features
Data transfer rate5000 Mbit/s
Product colourBlack
Housing materialMetal
LED indicatorsYes
Cable typeRound cable
Cable length0.8 m
CertificationCE, UKCA, FCC, RoHS & REACH, California Proposition 65
Power
Power supply typeDC
Weight & dimensions
Width125 mm
Depth74.6 mm
Height22 mm
Weight256 g
Packaging data
Quantity per pack1 pc(s)
Package width260 mm
Package depth180 mm
Package height70 mm
Package weight650 g
Package typeBox
Packaging content
ManualYes
Operational conditions
Minimum operating temperature0 °C
Maximum operating temperature50 °C
Operating temperature (T-T)0 - 50 °C
Operating temperature (T-T)-20 - 60 °F
Operating relative humidity (H-H)0 - 90%
Sustainability
Sustainability complianceYes
Technical details
Compliance certificatesCE, Federal Communications Commission (FCC), REACH, RoHS, UKCA
