Description

SilverNet SIL-WCAP-AX-EXT, 2.4 GHz, 5 GHz, 1800 Mbit/s, WEP, WPA, WPA-AES, WPA-Enterprise, WPA-PSK, WPA-TKIP, WPA2, WPA2-AES, WPA2-Enterprise, WPA2-PSK,..., 10,100,1000 Mbit/s

The SIL WCAP-AX-EXT is a powerful, IP67 wireless outdoor access point.

As part of the new Intelligent Wi-Fi 6 "Aero" range by SilverNet, the cloud-managed WCAP-AX-EXT is designed to build high performance enterprise Wi-Fi networks, while also making enterprise management simple.

This equipment offers an exceptional outdoor Wi-Fi range with a TX-Power of up to 23dBm and a coverage distance of up to 200 meters, making it perfect for a variety of uses, especially in commercial and hospitality settings. It provides robust support for hotspot functionality and supports multiple authentication methods, including vouchers, local accounts, and social media platforms like Facebook, making it suitable for shopping centers, schools, hotels, and more.

The access point can be managed locally or through the cloud, offering the versatility needed to provide a comprehensive, managed Wi-Fi service tailored to your clients' requirements. It also operates efficiently as a standalone access point.

Maintain smooth operations for you and your clients. Stay updated on the health of your clients' Wi-Fi signals and internet quality, reducing the frequency of unnecessary support calls. Tasks such as RF troubleshooting and mass software updates are simplified, and the installation process is quick and straightforward.

The durable exterior of the device shields it from external interferences, including other signals and harsh weather conditions. With a standard 1-year warranty, you can have peace of mind.

Specifications

BrandSILVERNET
Manufacturer part no.SIL-WCAP-AX-EXT
Our part no.CI87893
CategoryNetworking › Wireless Access Points
Weight0 kg
Features
2.4 GHzYes
5 GHzYes
Maximum data transfer rate1800 Mbit/s
Maximum data transfer rate (2.4 GHz)600 Mbit/s
Maximum data transfer rate (5 GHz)1200 Mbit/s
Ethernet LAN data rates10,100,1000 Mbit/s
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3af
Cabling technology10/100/1000Base-T(X)
Number of users100 user(s)
Rate limitingYes
User-based bandwidth limitingYes
Automatic interference avoidanceYes
Wireless isolationYes
Band steeringYes
Quality of Service (QoS) supportYes
Maximum outdoor range200 m
Transmitting power (CE)23 dBm
Security
Security algorithmsWEP, WPA, WPA-AES, WPA-Enterprise, WPA-PSK, WPA-TKIP, WPA2, WPA2-AES, WPA2-Enterprise, WPA2-PSK, WPA2-TKIP
MAC address filteringYes
Service Set Identifier (SSID) featuresMultiple SSIDs
Number of SSID supported8
Management features
Web-based managementYes
Firmware upgradeableYes
Ports & interfaces
WAN connectionEthernet (RJ-45)
Power
Power over Ethernet (PoE)Yes
Output voltage48 V
Power consumption (max)15 W
Design
PlacementPole, Wall
Product colourWhite
International Protection (IP) codeIP67
Reset buttonYes
LED indicatorsLAN, Power, WAN
Antenna
Antenna typeExternal
Number of connectors4
Performance
Built-in processorYes
Flash memory128 MB
Internal memory512 MB
Certificates
CertificationCE, RoHS
Weight & dimensions
Width231 mm
Depth295 mm
Height80 mm
Packaging data
Package width230 mm
Package depth380 mm
Package height107 mm
Package weight1.62 kg
Package typeBox
Packaging content
Quantity per pack1 pc(s)
PoE adapter includedYes
Mounting kitYes
Quick start guideYes
Operational conditions
Operating relative humidity (H-H)5 - 95%
Operating temperature (T-T)-30 - 70 °C
Storage temperature (T-T)-40 - 70 °C
Logistics data
UK Trade Tariff code85176200
Warranty period1 year(s)
