Description
Manhattan Wall Mount for TV & Monitors (Tiltable), For screens 32" to 55", VESA compatibility: all between 200x200mm to 400x400mm - check the dimensions of the four mounting holes on back of screen to ensure it fits, Max 35kg, Black, Bracket, 177.8 cm (70"), 75 x 75 mm, 400 x 400 mm, -8 - 0°, Steel, Black
Slim and strong Tilting TV Wall Bracket - adjustable mounting bracket puts displays in the right perspective and avoids annoying glare This tilting TV Wall Mount from Manhattan safely holds your TV and offers a toolless 0 to -8° tilt adjustment for optimized views. It fits flat LCD, OLED or plasma TVs up to 70"" and weighing up to 45 kg (100 lbs.) with VESA compliance up to 400x400. You're all set for a confident above-the-floor installation with intuitive snap-in spring locks with release cords that let you easily and securely put the TV in place. It's ideal for residential, office, hospitality, classroom, conference room, digital signage and other commercial applications.
Specifications
| Brand | MANHATTAN |
|---|---|
| Manufacturer part no. | 462402 |
| Our part no. | CJ40269 |
| EAN | 0766623462402 |
| Category | Monitors & Displays › Monitor Mounts & Stands |
| Weight | 1 kg |
| Mounting | |
| Maximum weight capacity | 48 kg |
| Minimum screen size | 81.3 cm (32") |
| Number of displays supported | 1 |
| Maximum screen size | 177.8 cm (70") |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 400 x 400 mm |
| Panel mounting interface | 75 x 75,100 x 100,100 x 150,100 x 200,150 x 100,150 x 150,200 x 100,200 x 200,200 x 300,200 x 400,300 x 400,300 x 300,300 x 200,400 x 200,400 x 400,400 x 300 |
| Mounting type | Wall |
| Ergonomics | |
| Tilt adjustment | Yes |
| Tilt angle range | -8 - 0° |
| Distance to the wall (max) | 2 cm |
| Design | |
| Product colour | Black |
| Housing material | Steel |
| Technical details | |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Manual | Yes |
| Mounting kit | Yes |
| Packaging content | Low-Profile Tilting TV Wall Mount Installation hardware with instructions |
| Weight & dimensions | |
| Width | 440 mm |
| Depth (max) | 2 cm |
| Height | 418 mm |
| Weight | 700 g |
| Packaging data | |
| Package width | 450 mm |
| Package depth | 28 mm |
| Package height | 175 mm |
| Package weight | 1 kg |
| Package type | Box |
| Logistics data | |
| Master (outer) case width | 470 mm |
| Master (outer) case length | 370 mm |
| Master (outer) case height | 280 mm |
| Master (outer) case gross weight | 20.2 kg |
| Products per master (outer) case | 18 pc(s) |
