Description
APC GVSUPS30KB5FS, 30 kVA, 30000 W, Sine, 200 V, 220 V, 40 - 70 Hz
Highly efficient, easy-to-deploy 30 kW, 208 V 3-phase UPS that brings best-in-class power protection and low total cost of ownership to edge, small and medium data centers, as well as to critical infrastructure in commercial and industrial applications. Includes 5x8 start-up service and 3 smart modular high capacity battery strings, expandable to 5 strings for extended runtime. See the battery runtime chart for details.
Specifications
| Brand | APC |
|---|---|
| Manufacturer part no. | GVSUPS30KB5FS |
| Our part no. | CJ84936 |
| EAN | 0731304409731 |
| Category | Power & UPS › UPS |
| Weight | 665 kg |
| Features | |
| Output power capacity | 30 kVA |
| Output power | 30000 W |
| Waveform | Sine |
| Input operation voltage (min) | 200 V |
| Input operation voltage (max) | 220 V |
| Input frequency | 40 - 70 Hz |
| Output frequency | 50/60 Hz |
| Maximum current | 107 A |
| Heat dissipation | 6526 BTU/h |
| Number of input phases | 3 |
| Number of output phases | 3 |
| Input power factor | 0.99 |
| Crest factor | 2.5:1 |
| Output voltage Total Harmonic Distortion (THD) | 1% |
| Input current Total Harmonic Distortion (THD) | 3% |
| Noise level | 54 dB |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery voltage | 480 V |
| Design | |
| Product colour | White |
| International Protection (IP) code | IP20 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 10 - 80% |
| Operating altitude | 0 - 1000 m |
| Technical details | |
| Minimum order quantity | 1 pc(s) |
| Packaging content | |
| Management card included | Yes |
| Weight & dimensions | |
| Width | 550 mm |
| Depth | 847 mm |
| Height | 1970 mm |
| Weight | 665 kg |
| Packaging data | |
| Package width | 550 mm |
| Package depth | 847 mm |
| Package height | 197 mm |
| Package weight | 665 kg |
| Logistics data | |
| Warranty period | 1 year(s) |
