Description

Owl Labs Owl Bar Video Conferencing Device — 4K Video Conferencing Bar with Active Speaker Focus (Add a Meeting Owl 3 or Pro for 360-Degree Coverage and Automatic Camera Switching), Video collaboration bar, CMOS, 4K Ultra HD, 30 fps, Charcoal

Our intelligent 114° 4K front-of-room camera, mic, and speaker device. Featuring a 4K, 30MP camera lens, 4 omnidirectional microphones, and an integrated speaker. Pairs with the Meeting Owl 3 or Pro (sold separately) to automatically focus on whoever is speaking and switch between cameras to always share the best perspective of the room for remote participants.

Front and center room coverage with intelligent camera-switching and automatic speaker focus to capture every angle Clear video and audio with 4K 30MP camera, 4 omnidrectional mics, and high-fidelity speaker Pairs seamlessly with other Owl Labs solutions, including the Meeting Owl, the Whiteboard Owl and the Expansion Mic, to foster active collaboration and increased participation

Specifications

BrandOWL LABS
Manufacturer part no.FRS100-2100
Our part no.CK81998
EAN0850022203961
CategoryNetworking › Video Conferencing
Weight5.4 kg
Performance
Number of cameras1
Product colourCharcoal
Product typeVideo collaboration bar
Video
HD type4K Ultra HD
Maximum video resolution3840 x 2160 pixels
Supported video modes360p, 1080p, 1440p, 2160p
Supported graphics resolutions640 x 360, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160
Maximum frame rate30 fps
Video formats supportedMJPG, NV12
Audio
Built-in speaker(s)Yes
Number of speakers1
Output level79/1 dB
RMS rated power5 W
Microphone pick-up range2.5 m
Ports & interfaces
HDMI ports quantity1
USB connector typeUSB Type-C
Network
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Security algorithmsWPA2, WPA3
Camera
Megapixel (approx.)30 MP
Camera typeSingle camera
Effective sensor resolution48 MP
Sensor typeCMOS
Focal length range500 - 5000 mm
Horizontal field of view114°
Vertical field of view73°
Microphone
Microphone sensitivity69 dB
Microphone frequency100 - 10000 Hz
Microphone direction typeOmnidirectional
Number of microphones4
Logistics data
Country of originVietnam
Harmonized System (HS) code8525.5000.00
Computer system
Processor familySnapdragon
Processor modelQCS8250
Windows operating systems supportedYes
Mac operating systems supportedYes
Other operating systems supportedChromeOS, Linux
Power
Power source typeDC
DC output voltage19 V
Certificates
Certified for Microsoft TeamsYes
Weight & dimensions
Width97 mm
Depth769 mm
Height76 mm
Weight1.88 kg
Packaging data
Package width149 mm
Package depth820 mm
Package height162 mm
Package weight5 kg
Packaging content
Cables includedAC, USB Type-C
Wall mounting kitYes
Warranty cardYes
Quick start guideYes
Packaging contentOwl Bar Table / Wall mount 6' USB Type C Cable Power supply AC line cord QSG Table card english Table card french Safety/regulatory/warranty slipsheet Owl card holder Room Solution card Owl Labs sticker
