Description
StarTech.com 1ft (30cm) HDMI to DisplayPort Adapter Cable, 8K 60Hz, Active HDMI 2.1 to DP 1.4 Video Converter, USB Bus Powered with Included Cable, 0.3 m, HDMI Type A (Standard), DisplayPort, Male, Female, Straight
Connect an HDMI-enabled source to a DisplayPort monitor with support for resolutions up to 8K at 60Hz
This HDMI 2.1 to DisplayPort 1.4 adapter connects an 8K 60Hz HDMI video source, such as a laptop or desktop, to a DisplayPort monitor.
8K 60Hz Resolution
This 1ft (30cm) HDMI to DisplayPort video converter supports resolutions up to 7680 x 4320 at 60Hz*. It supports HDR, HDCP 2.3, CEC, ARC, and 2-channel DisplayPort audio. Additionally, it supports lower resolutions such as 4K 120Hz, 4K 60Hz, and 1080p.
*DSC support on the host is required to achieve maximum video performance.
No Drivers or Software Required
This universal active adapter utilizes integrated or dedicated GPUs, enabling high-performance video with minimal CPU usage. It requires no drivers or software and works with any HDMI-enabled laptop, desktop, Ultrabook, MacBook, or Chromebook. It is compatible with any operating system, including Windows, macOS, Ubuntu, and ChromeOS.
Extended Cables
This HDMI to DP adapter features a 1ft (30cm) cable between the HDMI and DP connectors, reducing strain on ports and connectors. The adapter includes a 1.6-foot (50cm) USB power cable for connecting to a powered USB port anywhere on the laptop or to a USB wall charger. Power is required for the adapter to function.
Specifications
| Brand | STARTECH |
|---|---|
| Manufacturer part no. | 148B-HDMI-DP-8K |
| Our part no. | CK87907 |
| EAN | 0065030900867 |
| Category | Cables & Adapters › Display Cables |
| Weight | 0 kg |
| Features | |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Power source | USB |
| Cable length | 0.3 m |
| Connector 1 | HDMI Type A (Standard) |
| Connector 2 | DisplayPort |
| Connector 1 gender | Male |
| Connector 2 gender | Female |
| HDMI version | 2.1 |
| HDCP | Yes |
| HDCP version | 1.4/2.2/2.3 |
| DisplayPort version | 1.4 |
| High Dynamic Range (HDR) supported | Yes |
| Maximum resolution | 7680 x 4320 pixels |
| Supported graphics resolutions | 800 x 600 (SVGA), 832 x 624, 1024 x 768 (XGA), 1152 x 870, 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1366 x 768, 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2048 x 1536 (QXGA), 2560 x 1440, 3072 x 1728, 3200 x 1800, 3840 x 2160, 5120 x 2880, 7680 x 4320 |
| Maximum refresh rate | 120 Hz |
| Refresh rate at maximum resolution | 60 Hz |
| Product colour | Black, Silver |
| Chipset | LT6711GX-U3 |
| Cable type | Round cable |
| Colour depth | 10 bit |
| Colour sampling | 4:4:4 |
| Audio Return Channel (ARC) | Yes |
| Plug and Play | Yes |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Other operating systems supported | ChromeOS |
| Certificates | |
| Compliance certificates | RoHS |
| Sustainability | |
| Sustainability compliance | Yes |
| Weight & dimensions | |
| Weight | 32 g |
| Width | 31 mm |
| Depth | 372 mm |
| Height | 12 mm |
| Packaging data | |
| Package width | 127 mm |
| Package depth | 163 mm |
| Package height | 19 mm |
| Package weight | 51 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Master (outer) case width | 467 mm |
| Master (outer) case length | 363 mm |
| Master (outer) case height | 288 mm |
| Products per master (outer) case | 80 pc(s) |
