Description
Eaton 160 -294V Input Rack Mount Uninterruptible Power Supply, 650VA (520W), 5P650I, Line-Interactive, 0.65 kVA, 520 W, 160 V, 294 V, 50/60 Hz
Specifications
| Brand | EATON |
|---|---|
| Manufacturer part no. | 5P650IG2BS |
| Our part no. | CL10881 |
| EAN | 3553340710421 |
| Category | Power & UPS › UPS |
| Weight | 8 kg |
| Features | |
| UPS topology | Line-Interactive |
| Output power capacity | 0.65 kVA |
| Output power | 520 W |
| Input operation voltage (min) | 160 V |
| Input operation voltage (max) | 294 V |
| Input frequency | 50/60 Hz |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Heat dissipation | 461 BTU/h |
| Noise level | 35 dB |
| Battery | |
| Battery technology | Lead-Acid |
| Battery capacity | 9 Ah |
| Battery voltage | 12 V |
| Design | |
| Form factor | Tower |
| Product colour | Black, Silver |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Certificates | |
| Certification | IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 UL 1778 CSA-C22.2 CE UKCA Cm Ukr KCC cTUVus BIS |
| Packaging content | |
| Cables included | USB cable |
| Quick installation guide | Yes |
| Weight & dimensions | |
| Width | 150 mm |
| Depth | 345 mm |
| Height | 233 mm |
| Weight | 8.16 kg |
