Epson TM-U220IIB (102): Serial, PS, NE sensor, EDG, Dot matrix, POS printer, 4.7 lps, 16 cpi, 8.3 cm, Wired

Easy-to-use impact printer Easy to use, compact and versatile, the TM-U220II impact receipt printer is perfect for a wide variety of applications. The increased buffer size allows more orders to be received at the same time, while the printing speed provides high-efficiency throughput.

Easy to use The TM-U220II is a robust, high performance impact receipt printer which is exceptionally easy to use. Featuring drop-in paper load, selectable auto-cutter and clamshell covers for easy access and maintenance, the TM-U220II is very reliable and prints on plain paper in three widths.

Increased memory An increased buffer allows more orders to be received at the same time, making it ideal for those busy environments where order success is critical. It supports more orders being received from multiple devices, which means that more tickets can be processed in a shorter time, keeping the operation flowing.

High printing speed The TM-U220II provides high-efficiency throughput. Retailers can hand receipts to customers faster. Restaurant kitchens can receive orders quickly.

Superior versatility The TM-U220II suits a wide range of needs and applications. Each model in the series is powerful, yet compact enough to fit in confined spaces. In addition, the wall-mounting option frees up valuable counter space in kitchens and other tight locations.

Outstanding compatibility The TM-U220II printers are designed to be compatible with systems built around predecessor models. These systems can be upgraded simply by dropping in a TM-U220II. Moreover, since the external dimensions are nearly identical, there is no need to change the installation environment.

Distinctive sound The distinctive printing sound of the TM-U220II makes it stand out among the soundscape of a noisy kitchen environment. This draws attention to incoming orders and reduces the customers' waiting times.

Specifications

BrandEPSON
Manufacturer part no.C31CL27102
Our part no.CL13219
EAN8715946732602
CategoryLabel & Receipt Printers › Desktop Label Printers
Weight3.8 kg
Printing
Print speed4.7 lps
Character density16 cpi
Print technologyDot matrix
TypePOS printer
Paper handling
Maximum roll diameter8.3 cm
Ports & interfaces
USB portNo
Serial interfaceYes
Serial interface typeRS-232
Connectivity technologyWired
InterfaceRS-232, Drawer kick-out
Network
Ethernet LANNo
Wi-FiNo
Features
Page description languagesESC/POS
Sound pressure level (printing)64 dB
Mean time between failures (MTBF)180000 h
CutterYes
Autocutter durability0.8 million cuts
Receive buffer40 KB
Design
Product colourDark Grey
Power
Power source typeAC
Power consumption (printing)31 W
AC input voltage24 V
Operational conditions
Storage temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)10 - 90%
Weight & dimensions
Width160 mm
Depth248 mm
Height139 mm
Weight2.5 kg
Packaging data
Quantity per pack1 pc(s)
Package width30 mm
Package depth33 mm
Package height22 mm
Package weight3.84 kg
Logistics data
Products per pallet72 pc(s)
Products per pallet layer8 pc(s)
Pallet gross width80 cm
Pallet gross length120 cm
Pallet gross height34.8 cm
Products per pallet (UK)108 pc(s)
Products per pallet layer (UK)12 pc(s)
Pallet length (UK)120 cm
Pallet height (UK)34.8 cm
Technical details
Font stylesANK, Traditional Chinese, Simplified Chinese
Box contentsAC adapter, C, Main unit, Ribbon, Roll paper, User manual
Paper size roll paper76.00 &plusmn; 0.50 (W) mm x dia 83.00 mm,<br>69.50 &plusmn; 0.50 (W) mm x dia 83.00 mm,<br>57.50 &plusmn; 0.50 (W) mm x dia 83.00 mm
TechnologySerial Impact Dot Matrix
Voltage24 V
Power consumptionPrinting: Appx.31 W, Standby: Appx.2 W
Other features
Buffer size20 KB
