Description
NETGEAR GS724T, Managed, L2+/L3, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting, 1U
NETGEAR GS724T Smart Cloud Switch offers powerful L2 and L2+/Layer 3 Lite features and enhanced performance and usability. Manage remotely with Insight Cloud Management
Total Network Solution helps you get the most out of your network
Easily deploy, manage, and monitor NETGEAR Insight managed routers, switches, and access points all from a single pane-of-glass.
Specifications
| Brand | NETGEAR |
|---|---|
| Manufacturer part no. | GS724T-600EUS |
| Our part no. | CL25676 |
| EAN | 0606449169119 |
| Category | Networking › Managed Switches |
| Weight | 2.8 kg |
| Management features | |
| Switch type | Managed |
| Switch layer | L2+/L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| System event log | Yes |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 2 |
| Power connector | DC-in jack |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1ab, IEEE 802.1as, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3x, IEEE 802.3z |
| 10G support | Yes |
| Port mirroring | Yes |
| Full duplex | Yes |
| IP routing | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Number of VLANs | 256 |
| Data transmission | |
| Switching capacity | 52 Gbit/s |
| MAC address table | 16000 entries |
| Number of queues | 8 |
| Number of static routes | 32 |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Packet buffer memory | 2 MB |
| Security | |
| DHCP features | DHCP client, DHCP snooping |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| Security algorithms | HTTPS, SSL/TLS |
| MAC address filtering | Yes |
| SSH/SSL support | Yes |
| Multicast features | |
| Multicast support | Yes |
| Number of multicast groups filtered | 512 |
| Protocols | |
| Management protocols | SNMP v1/v2 |
| Design | |
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Blue, Grey |
| LED indicators | Activity, Link |
| Number of fans | 0 fan(s) |
| Performance | |
| Noise level | 0 dB |
| Firmware upgradeable | Yes |
| Mean time between failures (MTBF) | 1999946 h |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (typical) | 13.5 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 3000 m |
| Weight & dimensions | |
| Width | 328 mm |
| Depth | 169 mm |
| Height | 43 mm |
| Weight | 1.62 kg |
