Description
APC Smart-UPS Ultra On-Line, 5000VA, Lithium-ion, Rack/Tower 2U, 230V, Hardwired 3-Wire Output, Network Card, Extended runtime, W/rail kit, Double-conversion (Online), 5 kVA, 5000 W, Sine, 180 V, 275 V
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 5KVA on-line 2U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with Hardwired input and Hardwired 3-Wire output. It embeded Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 5-year warranty on the UPS and Lithium-ion battery.
Specifications
| Brand | APC |
|---|---|
| Manufacturer part no. | SRTL5KRM2UI-HW |
| Our part no. | CL43601 |
| EAN | 0731304738015 |
| Category | Power & UPS › UPS |
| Weight | 44.5 kg |
| Features | |
| UPS topology | Double-conversion (Online) |
| Output power capacity | 5 kVA |
| Output power | 5000 W |
| Waveform | Sine |
| Input operation voltage (min) | 180 V |
| Input operation voltage (max) | 275 V |
| Input frequency | 40 - 70 Hz |
| Output operation voltage (max) | 220 V |
| Surge energy rating | 1260 J |
| Heat dissipation | 931 BTU/h |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Single-phase input voltage supported | 230 V |
| Noise level | 55 dB |
| Ports & interfaces | |
| AC outlet types | Hard Wire 3-wire (1PH + N + G) |
| Battery | |
| Battery replacement accessibility | End-user |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery voltage | 180 V |
| Battery recharge time | 1.5 h |
| Design | |
| Form factor | Rackmount |
| Rack capacity | 2U |
| Product colour | Silver, Grey |
| International Protection (IP) code | IP20 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 15240 m |
| Technical details | |
| Sustainable packaging | No |
| Packaging recycled materials | Recycled cardboard |
| SCIP number | 5ee38369-4dfb-4636-ab65-b08aa3242891 |
| Preferred mounting position | no preference |
| Take-back system | No |
| Packaging without single use plastic | No |
| Certificates | |
| Waste Electrical and Electronic Equipment (WEEE) compliance | Yes |
| Compliance certificates | RoHS, REACH, WEEE |
| Certification | CE; UKCA; EN/IEC 62040-1 |
| Weight & dimensions | |
| Width | 432 mm |
| Depth | 701 mm |
| Height | 86 mm |
| Weight | 29.2 kg |
| Packaging data | |
| Package width | 585 mm |
| Package depth | 984 mm |
| Package height | 392 mm |
| Package weight | 38.5 kg |
| Logistics data | |
| Customs product code (TARIC) | 8504409590 |
| Total carbon footprint (kg of CO2e) | 8395.6203440278 |
| Warranty period | 5 year(s) |
| Country of origin | Philippines |
| Other features | |
| Output connection type | hard wire 3-wire (1P + N + E) for 1 zone(s) |
| Output voltage | 230 V |
| Mounting | front; horizontal |
| Optimising energy efficiency | Energy efficient product |
