StarTech.com 10ft (3m) White VESA Certified DisplayPort 1.2 Cable, 4K 60Hz, 21.6Gbps, Latching DP Connectors, DP 1.2 DisplayPort Cable, DP Monitor Cord, M/M, 3 m, DisplayPort, DisplayPort, Male, Male, 4096 x 2160 pixels

Enable seamless 4K 60Hz video using this VESA-Certified DP 1.2 Cable

Connect a 4K UHD DisplayPort monitor to a host computer or MST hub, using this VESA-Certified DisplayPort 1.2 Cable. The connector markings enable quick visual identification, distinguishing this cable from other similar-looking or unmarked DP cables. Eliminate guesswork and always choose the appropriate cable to support full DP 1.2 capabilities.

Seamless Compatibility

For seamless operation between DisplayPort-enabled devices, the DisplayPort 1.2 Cable is VESA Certified for guaranteed DP 1.2 and backward compatibility. Certified cables provide consistent, reliable performance across multiple resolutions and refresh rates.

Durable Design

This DisplayPort cable features a flexible TPE outer jacket that routes easily around corners and desk edges. Robust strain reliefs enable convenient positioning of the cable, and latching nickel-plated DP connectors attach securely to prevent accidental disconnection.

Supported DisplayPort 1.2 Features:

This DisplayPort cable supports full DP 1.2 features:

• Resolutions up to 4K 60Hz using a compatible DP source and display • 21.6Gbps bandwidth supports high refresh rates including 1440p 144Hz and 1080p 240Hz • High-Bandwidth Digital Content Protection (HDCP) 1.3 for a secure connection between source and display • Multi-Stream Transport (MST) for daisy-chaining multiple monitors • Up to 8 Uncompressed Digital Audio Channels • 3D Stereo support for 3D video formats • Backward compatible with previous DP versions

This DP 1.2 Cable is constructed with braided aluminum mylar shielding to minimize EMI for clear, consistent audio/video output and long-term reliable performance.

Specifications

BrandSTARTECH
Manufacturer part no.DP12-CABLE-10FTW
Our part no.CL44136
EAN0065030916028
CategoryCables & Adapters › Display Cables
Weight0.1 kg
Features
Connector 1 form factorStraight
Connector 2 form factorStraight
Connector contacts platingNickel
DisplayPort version1.2
Maximum resolution4096 x 2160 pixels
Supported graphics resolutions2560 x 1440, 4096 x 2160, 1920 x 1080 (HD 1080)
Supported video modes1080p, 1440p, 2160p
Maximum refresh rate240 Hz
HDCPYes
HDCP version1.3
Cable length3 m
Connector 1DisplayPort
Connector 2DisplayPort
Connector 1 genderMale
Connector 2 genderMale
Latching connectorsYes
Product colourWhite
Cable shieldingAluminum mylar foil
AWG wire size28
Data transfer rate21.6 Gbit/s
Channels quantity7.1 channels
Multi-Stream Transport (MST)Yes
Number of conductors19
Fire-resistance ratingVW-1
Cable typeRound cable
Operational conditions
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)5 - 85%
Weight & dimensions
Cable diameter7.5 mm
Weight192 g
Packaging data
Package width200 mm
Package depth220 mm
Package height20 mm
Package weight200 g
Logistics data
Master (outer) case width320 mm
Master (outer) case length500 mm
Master (outer) case height190 mm
Products per master (outer) case30 pc(s)
