Description

Vertiv Liebert GXT5 Lithium-Ion Online UPS 1000 VA/1000 W 230 V Rack/Tower, Double-conversion (Online), 1 kVA, 1000 W, Pure sine, 115 V, 280 V

The Vertiv Liebert GXT5 Lithium-Ion UPS protects critical IT applications against outages and various power disturbances. This online UPS offers the highest level of power conditioning and battery backup in server rooms, network closets, and other edge or distributed IT locations. Lithium LFB batteries require fewer battery replacements and last up to 3x as long as traditional VRLA batteries reducing maintenance, labor, and replacement costs (resulting in the lowest TCO). Internal batteries offer industry-leading runtime (up to 14 minutes at full load (varies by model)) to protect critical equipment during an unexpected power loss. They offer better performance at higher temperatures, supports up to 10 times more discharge cycles, and delivers faster recharge times compared to VRLA batteries. Hot-swappable, user-replaceable batteries may increase the useable life of the UPS by allowing you to easily replace the batteries, if needed, without disrupting power to connected equipment.

Specifications

BrandVERTIV
Manufacturer part no.GXT5-1000IRT2UXLN
Our part no.CL58996
EAN4061471435285
CategoryPower & UPS › UPS
Weight23 kg
Features
UPS topologyDouble-conversion (Online)
Output power capacity1 kVA
Output power1000 W
WaveformPure sine
Input operation voltage (min)115 V
Input operation voltage (max)280 V
Input frequency40 - 70 Hz
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Efficiency (On-line mode)93%
Power factor0.99
Audible alarm(s)Yes
Ports & interfaces
AC outlet typesC13 coupler
Power plugC14 coupler
AC outlets quantity8 AC outlet(s)
USB portYes
Serial interfaceYes
Battery
Typical backup time at full load12 min
Typical backup time at half load26.5 min
Design
Form factorTower
Rack capacity2U
Product colourBlack
Display typeLCD
LED indicatorsYes
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 95%
Certificates
Compliance certificatesREACH, RoHS
CertificationUL1778,<SP>4th<SP>Ed.<BR>FCC<SP>Part<SP>15<SP>Class<SP>A<BR>ANSI<SP>C62.41<SP>Cat.<SP>B<BR>ISTA<SP>1A<BR>
Packaging content
Cables includedUSB cable
ManualYes
Quick installation guideYes
Sustainability
Sustainability certificatesENERGY STAR
Weight & dimensions
Width430 mm
Depth446 mm
Height85 mm
Weight15 kg
Packaging data
Package width570 mm
Package depth597 mm
Package height242 mm
Package weight21 kg
Logistics data
Country of originChina
Other features
Packaging contentGXT5LI UPS, USB Cable, Quick Install Guide (QIG), 4-Post Rack 2U Rail Kit, Tower Base Kit
