Description

Vertiv Liebert GXT5 Lithium-Ion Online UPS 1000 VA/1000 W 230 V Rack/Tower, Double-conversion (Online), 1 kVA, 1000 W, Pure sine, 115 V, 288 V

The Vertiv Liebert GXT5 Lithium-Ion UPS protects critical IT applications against outages and various power disturbances. This online UPS offers the highest level of power conditioning and battery backup in server rooms, network closets, and other edge or distributed IT locations. Lithium LFB batteries require fewer battery replacements and last up to 3x as long as traditional VRLA batteries reducing maintenance, labor, and replacement costs (resulting in the lowest TCO). Internal batteries offer industry-leading runtime (up to 14 minutes at full load (varies by model)) to protect critical equipment during an unexpected power loss. They offer better performance at higher temperatures, supports up to 10 times more discharge cycles, and delivers faster recharge times compared to VRLA batteries. Hot-swappable, user-replaceable batteries may increase the useable life of the UPS by allowing you to easily replace the batteries, if needed, without disrupting power to connected equipment.

Specifications

BrandVERTIV
Manufacturer part no.GXT5LI-1000IRT2UXLN
Our part no.CL58998
EAN4061471435315
CategoryPower & UPS › UPS
Weight23.6 kg
Features
UPS topologyDouble-conversion (Online)
Output power capacity1 kVA
Output power1000 W
WaveformPure sine
Input operation voltage (min)115 V
Input operation voltage (max)288 V
Input frequency40 - 70 Hz
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Efficiency95%
Efficiency (ECO mode)98%
Output power factor0.9
ECO modeYes
Emergency Power Off (EPO)Yes
Noise level48 dB
Surge protectionYes
Power protection featuresOver voltage, Under voltage
Ports & interfaces
AC outlet typesC13 coupler
AC outlets quantity8 AC outlet(s)
USB portYes
Serial interfaceYes
Serial ports quantity1
Battery
Battery technologyLithium-Ion (Li-Ion)
Typical backup time at full load12 min
Typical backup time at half load26.5 min
Battery recharge time2 h
Hot-swap batteryYes
Battery weight5.9 kg
Design
Form factorTower
Rack capacity2U
Product colourBlack
Display typeLCD
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Certificates
Compliance certificatesREACH, RoHS, WEEE
Weight & dimensions
Width430 mm
Depth446 mm
Height85 mm
Weight16 kg
Packaging data
Package width570 mm
Package depth597 mm
Package height242 mm
Package weight21 kg
