Description
StarTech.com 10ft (3m) DisplayPort 1.4 Extension Cable, DP 1.4 Port Saver Cable, 8K 60Hz, DP Male to Female Extension Adapter Cord, DisplayPort Extension Cable, TPE Jacket, M/F, 3 m, DisplayPort, DisplayPort, Male, Female, 7680 x 4320 pixels
Extend a DisplayPort 1.4 connection or safeguard against port/connector strain
This high quality DisplayPort 1.4 Extension Cable provides extra reach for greater setup versatility, and reduces wear and tear of the DP port on your monitor or other devices. The connector markings enable quick visual identification, distinguishing this cable from other similar-looking or unmarked DisplayPort cables. Eliminate guesswork and always choose the appropriate cable to support full DP 1.4 performance.
Full DisplayPort Capability
This male-to-female DisplayPort extension cable supports all DisplayPort 1.4 features:
• Resolutions up to 8K 60Hz or 4K 144Hz • High speeds with a bandwidth of up to 32.4Gbps • Multi-Stream Transport (MST) for daisy-chaining multiple monitors • High Dynamic Range (HDR) for higher contrast ratio and vivid colors • Crystal-clear sound with up to 32 digital audio channels
This DisplayPort extension cable is backwards compatible with earlier versions of DisplayPort, ensuring seamless integration with existing DisplayPort devices.
Specifications
| Brand | STARTECH |
|---|---|
| Manufacturer part no. | 10F-DP14-EXTEND-CBL |
| Our part no. | CM61947 |
| EAN | 0065030916318 |
| Category | Cables & Adapters › HDMI Cables & Extenders |
| Weight | 0.2 kg |
| Features | |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Connector contacts plating | Gold |
| DisplayPort version | 1.4 |
| Maximum resolution | 7680 x 4320 pixels |
| Supported graphics resolutions | 3840 x 2160, 7680 x 4320 |
| Maximum refresh rate | 144 Hz |
| Cable length | 3 m |
| Connector 1 | DisplayPort |
| Connector 2 | DisplayPort |
| Connector 1 gender | Male |
| Connector 2 gender | Female |
| Product colour | Black |
| Cable material | Copper |
| Cable shielding | Aluminum mylar foil |
| Jacket material | Thermoplastic elastomer (TPE) |
| AWG wire size | 30 |
| High Dynamic Range (HDR) supported | Yes |
| Bandwidth | 32400 MB/s |
| Multi-Stream Transport (MST) | Yes |
| Fire-resistance rating | VW-1 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 5 - 85% |
| Certificates | |
| Compliance certificates | CE, RoHS |
| Sustainability | |
| Doesn't contain | Halogen |
| Weight & dimensions | |
| Cable diameter | 8.4 mm |
| Weight | 240 g |
| Packaging data | |
| Package width | 201 mm |
| Package depth | 187 mm |
| Package height | 39 mm |
| Package weight | 246 g |
| Logistics data | |
| Master (outer) case width | 500 mm |
| Master (outer) case length | 320 mm |
| Master (outer) case height | 210 mm |
| Products per master (outer) case | 40 pc(s) |
