Description
Eaton N390-01M-12-AP, 1 m, OFNP, OS2, MPO/MTP, MPO/MTP
Premium 9/125 singlemode fiber optic cabling for transmitting 40/100 Gb data and voice signals over long distances. Designed for enterprise applications in wiring closets, telecom rooms and data centers.
9/125 Rated Singlemode Cable for 40/100 Gb Ethernet Applications - Designed for enterprise applications in wiring closets, telecom rooms and data centers - Recommended for QSFP+ applications in enterprise installations - Plenum-rated jacket suited for ceilings, walls and ducts - Yellow-colored for identification as a singlemode cable
MTP/MPO APC Connectors with Push/Pull Tabs - 12-fiber female connectors 12 times denser than SC connectors - APC connector angled to prevent light from reflecting back into laser - Push/pull tabs easy to install and remove with one hand - 100% tested for low insertion loss and back reflection
Specifications
| Brand | EATON |
|---|---|
| Manufacturer part no. | N390-01M-12-AP |
| Our part no. | CN25826 |
| Category | Cables & Adapters › Specialist Cables |
| Weight | 0 kg |
| Features | |
| Cable length | 1 m |
| Fibre optic type | OS2 |
| Cable shape | Round |
| Connector 1 | MPO/MTP |
| Connector 2 | MPO/MTP |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Cable type | OFNP |
| Product colour | Black, Green, Yellow |
| Full duplex | Yes |
| Core diameter | 9 µm |
| Cladding diameter | 125 µm |
| Fiber mode structure | Multi-mode |
| Jacket material | Polyvinyl chloride (PVC) |
| Certificates | |
| Compliance certificates | REACH, RoHS |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 60 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Packaging data | |
| Package width | 177.8 mm |
| Package depth | 12.7 mm |
| Package height | 228.6 mm |
| Package weight | 20 g |
| Logistics data | |
| Country of origin | China |
