Description

Brother TD-2320DSA300, Direct thermal, 300 x 300 DPI, 152.4 mm/sec, Wired, Black, Grey

The professional, high-resolution 2" desktop network label printer with 3.5" colour touch screen display.

Increasing productivity and reducing costs are key priorities in any workplace. And when it comes to label printing, the TD-2320DSA300 combines proven desktop printer performance with the versatility to operate in multiple locations, helping you to achieve greater efficiencies across your business. The TD-2320DSA300 works as a standalone printing solution with its 3.5" colour touch screen display and keyboard.

With a range of specialised features and high-quality print resolutions, the TD-2D is the perfect label printer for retail price mark down labels and food traceability ingredient labels – where you need to print high-quality labels in any location.

Complete print solution Optional accessories to suit your business needs.

Accessories include battery (PA-BT-004), cutter (PA-CU-004) or label peeler (PA-LP-002).

Professional print quality Print in high resolution up to 300dpi for any professional setting.

Space saving design A compact 2 inch label printer, designed to fit on most worksurfaces without compromising on working space.

Cut or peel A Cutter or peeler are the perfect accessories for adding efficiencies to your business.

Integrated USB host A USB-host port is built-in as standard, enabling a barcode reader or weighing scales to be connected. Barcodes are scanned to create print information.

Using pre-defined templates, your information is printed on to labels.

3.5" Colour touch screen A user-friendly colour touch screen display allows for stand alone printing and on-the-go editing of templates.

Specifications

BrandBROTHER
Manufacturer part no.TD2320DSA300ZU1
Our part no.CN73529
CategoryLabel & Receipt Printers › Mobile Label Printers
Weight0 kg
Printing
Print technologyDirect thermal
ColourNo
Maximum resolution300 x 300 DPI
Print speed152.4 mm/sec
Maximum printing width5.9 cm
Paper handling
Maximum label length3 m
Ports & interfaces
Connectivity technologyWired
Ethernet LANYes
Wi-FiNo
USB portYes
USB 2.0 ports quantity1
Performance
Internal memory256 MB
Flash memory64 MB
Built-in barcodesAZTECCODE, Data Matrix, MSI, CODABAR (NW-7), UPC-A, MaxiCode, Micro QR Code, UPC-E, EAN13, Code 128 (A/B/C), EAN8, POSTNET, Code 39, GS1 DataBar, QR Code, Code 93
Design
Product colourBlack, Grey
Built-in displayYes
Display diagonal8.89 cm (3.5")
Colour displayYes
Control typeButtons, Touch
System requirements
Windows operating systems supportedWindows 10, Windows 11
Server operating systems supportedWindows Server 2016, Windows Server 2019, Windows Server 2022
Mobile operating systems supportedAndroid, iOS
Operational conditions
Operating relative humidity (H-H)20 - 80%
Storage relative humidity (H-H)10 - 90%
Operating temperature (T-T)5 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Weight & dimensions
Width215 mm
Depth110 mm
Height172 mm
Weight1.33 kg
Packaging content
Cables includedAC, USB
Other features
Warranty period3 year(s)
