Description
D-Link 5G Transit Router, Cellular network gateway, Black, Gigabit Ethernet, 10,100,1000 Mbit/s, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
5G SA & NSA Leverage flexible 4G/5G dual-mode compatibility to adapt seamlessly to diverse carrier networks.
Wi-Fi 6 AX1800 Enhanced service efficiency via high-speed Wi-Fi for seamless access for passenger and connected devices.
Dual-SIM Failover Two SIM slots with failover redundancy for critical applications to ensure reliable cellular WAN connectivity and business continuity.
EN50155 / E-Mark Certified Compliant with EN50155 and E-Mark certifications to ensure the reliability and safety for the smart transportation.
GPS Location Real-time tracking enables routing services to minimize travel time and optimize fleet efficiency.
Wide Voltage Input Range Safely accepts power input from various on-board power sources for convenient installation.
Enhanced Passenger Wi-Fi and Real-Time Telematics The DTM-550-G 5G Transit Gateway transforms public transport experiences by providing high-speed in-vehicle Wi-Fi and real-time content updates. Passengers can enjoy seamless internet access and receive instant updates on weather and advertisements directly on digital signage, enhancing satisfaction in intelligent public transportation.
Optimize Vehicle Operation with Location-Based Services The DTM-550-G equips fleet vehicles with precise GPS location positioning, integrating seamlessly into customer’s fleet management for real-time vehicle tracking, and optimizing route planning. This enhances operational visibility and efficiency and supports improved decision-making.
Robust Design with Vibration/Shock Resistance Certified with EN50155 and E-Mark, the DTM-550-G design withstands vibrations, shocks, and extreme temperatures, ensuring data transmission stability even in moving vehicles. Ideal for demanding M2M applications in public transportation, it meets rigorous safety and regulatory standards for seamless automotive integration.
Specifications
| Brand | D-LINK |
|---|---|
| Manufacturer part no. | DTM-550-G |
| Our part no. | CN95689 |
| EAN | 0790069475221 |
| Category | Networking › Routers |
| Weight | 1.3 kg |
| Design | |
| Device type | Cellular network gateway |
| Product colour | Black |
| Reset button | Yes |
| LED indicators | Yes |
| Ethernet LAN features | |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| DHCP server | Yes |
| Wireless LAN features | |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| WLAN data transfer rates supported | 574,1201 Mbit/s |
| Mobile network | |
| Data network | 4G, 5G |
| 4G standard | LTE |
| 5G standard | Sub6 NSA, Sub6 SA |
| Number of SIM cards | 2 |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 4 |
| Security | |
| Security algorithms | AES, WPA, WPA-PSK, WPA2, WPA2-PSK, WPA3-Enterprise, WPA3-SAE |
| Network address translation (NAT) | Yes |
| Firewall | Yes |
| DMZ support | Yes |
| Port forwarding | Yes |
| Performance | |
| Antenna type | External |
| Antenna connector type | SMA |
| Antennas quantity | 7 |
| Power | |
| Power source type | DC |
| Input voltage | 12 - 36 V |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Weight & dimensions | |
| Width | 160 mm |
| Depth | 120 mm |
| Height | 47 mm |
