Description

LG 55XS4P, Digital signage flat panel, 139.7 cm (55"), LED, 1920 x 1080 pixels, 24/7

Attract Passing Customers with a Bright Display Presented Through a Window

World’s First UL Verification for Display Anti-Discoloration Characteristics By focusing on the pain points of our customers, we obtained the world’s first UL Verification for Display Anti-Discoloration Characteristics. Our new technology helps prevent ‘screen-yellowing’, while safeguarding display quality and performance stability.

Window-facing Display LG offers advanced technical solutions for cost-effective operations. The XS4P can maintain an astonishing brightness of 4,000 nits, yet has lower power consumption compared to RGB panels at the same brightness level.

Brightness Beyond the Window A window-facing display requires higher nits, as it is exposed to direct sunlight through a window. The XS4P is designed especially for window-facing environments, providing brilliant brightness. Vibrant and dynamic content displayed through the window will attract customers to your business, despite the viewers wearing polarized sunglasses.

High-performance with webOS 6.0 Quad Core SoC (System-on-Chip) can execute several tasks at the same time without a separate media player. In addition, webOS 6.0 platform enhances not only user convenience with intuitive UI but also web-app integration with updated Node JS / Chromium version.

Remotely Managed, Real-time Mastery (Content Manager) A significant advantage of window-facing displays over temporary displays is their ability to effortlessly manage frequently changing promotional content and pricing information. LG’s web-based content solution is intuitive and user-friendly, providing users with complete access to current and historical data anytime, anywhere, through their mobile devices. This allows users to monitor, adjust, and control the unit remotely in real-time.

Wide Range of Operating Temperature The XS4P can be used under a wide range of operating temperature from 0℃ to 40℃.

Conformal Coating The conformal coating with dust protection shields the circuit and power boards from dust, metal particles, moisture, and other contaminants, providing solid durability and long-term reliability.

Upgraded Quiet Mode The XS4P addresses concerns about display noise. It features an Upgraded Quiet Mode that operates at 2,500 nits with minimal fan noise.

Professional Content Partners Pairing the XS4P Series with LG SW solutions would enhance its utilization.

Convenient Installation with Calculated Precision The XS4P is equipped with a Leveler Tool that shows users the tilt of the device, allowing for precise display installation. Additionally, the Horizontal Sensor Tool assists users in verifying the correct installation direction. The XS4P even provides warning messages for proper installation if it is installed incorrectly.

Specifications

BrandLG ELECTRONICS
Manufacturer part no.55XS4P-B
Our part no.CO78672
EAN8806096166239
CategoryMonitors & Displays › Interactive & LED Displays
Weight20.6 kg
Display
Panel typeIPS
LED backlightYes
LED backlighting typeDirect-LED
Display diagonal139.7 cm (55")
Display technologyLED
Display resolution1920 x 1080 pixels
Display brightness4000 cd/m²
HD typeFull HD
TouchscreenNo
Native aspect ratio16:9
Response time9 ms
Contrast ratio (typical)1000:1
Contrast ratio (dynamic)500000:1
Viewing angle, horizontal178°
Viewing angle, vertical178°
Display number of colours16.7 million colours
Panel life50000 h
Native refresh rate60 Hz
Haze rate3%
Ports & interfaces
HDMI ports quantity2
HDMI input ports quantity2
DVI-D ports quantity1
DisplayPorts quantity2
DisplayPorts in1
DisplayPorts out1
USB portYes
USB ports quantity1
USB version2.0
USB connector typeUSB Type-A
Ethernet LAN (RJ-45) ports1
Audio (L/R) out1
RS-232CYes
Infrared data portYes
Remote (IR) input1
Remote (IR) output1
Audio
Built-in speaker(s)Yes
RMS rated power20 W
Design
Product designDigital signage flat panel
Placement supportedOutdoor
OrientationHorizontal/Vertical
Product colourBlack
Screen shapeFlat
VESA mountingYes
Panel mounting interface600 x 400 mm
Bezel width (bottom)1.2 cm
Bezel width (side)9.9 mm
Bezel width (top)1.2 cm
Bezel colourBlack
Performance
PurposeRetail
On Screen Display (OSD)Yes
Number of OSD languages22
On Screen Display (OSD) languagesArabic, Simplified Chinese, Traditional Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Greek, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish
Operating hours (hours/days)24/7
HDCPYes
HDCP version1.4
Power
Power consumption (typical)375 W
Power consumption (off)0.5 W
Power consumption (max)400 W
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Heat dissipation1280 BTU/h
Computer system
Computer systemYes
Computer system typeSystem on Chip (SoC)
Internal memory16 GB
Operating system installedWebOS
Operating system version6.0
Weight & dimensions
Display width1235.5 mm
Display depth85.4 mm
Display height709.4 mm
Display weight26 kg
Packaging data
Package width1360 mm
Package depth844 mm
Package height231 mm
Package weight31.2 kg
Packaging content
Remote control includedYes
Cables includedAC, HDMI
Operational conditions
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80%
Network
Ethernet LANYes
Features
Suitable for outdoor useYes
Heat dissipation (max)1365 BTU/h
Technical details
Introduction year2024
Other features
ManualYes
