Samsung QB13C-T Digital signage flat panel 33 cm (13") LCD Wi-Fi 500 cd/m² Full HD Black Touchscreen Tizen 7.0 16/7

Description

Samsung QB13C-T, Digital signage flat panel, 33 cm (13"), LCD, 1920 x 1080 pixels, Wi-Fi, 16/7

Specifications

BrandSAMSUNG
Manufacturer part no.LH13QBCTBGBXEN
Our part no.CP94894
EAN8806097646969
CategoryMonitors & Displays › Other (0352)
Weight0 kg
Display
Panel typeADS
Display diagonal33 cm (13")
Display technologyLCD
Display resolution1920 x 1080 pixels
Display brightness500 cd/m²
HD typeFull HD
TouchscreenYes
Touchscreen technologyCapacitive
Response time30 ms
Contrast ratio (typical)600:1
Contrast ratio (dynamic)10000:1
Viewing angle, horizontal170°
Viewing angle, vertical170°
Pixel pitch0.153 x 0.153 mm
Display diagonal (metric)33 cm
Horizontal scan range30 - 81 kHz
Vertical scan range48 - 75 Hz
Haze rate25%
Pixel frequency (max)148.5 MHz
Ports & interfaces
HDMI ports quantity1
HDMI version1.4
DVI portNo
USB portYes
USB ports quantity2
Ethernet LAN (RJ-45) ports1
RS-232 interfaceYes
Audio
Built-in speaker(s)No
Design
Product designDigital signage flat panel
Placement supportedIndoor
Product colourBlack
VESA mountingYes
Panel mounting interface100 x 100 mm
Performance
PurposeRetail
TV tuner integratedNo
Operating hours (hours/days)16/7
HDCPYes
HDCP version2.2
Power
Power consumption (standby)0.5 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Computer system
Internal storage capacity8 GB
Operating system installedTizen 7.0
Weight & dimensions
Display width322 mm
Display depth22 mm
Display height193.5 mm
Display weight1.1 kg
Packaging data
Package width520 mm
Package depth238 mm
Package height64 mm
Package weight2 kg
Operational conditions
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80%
Network
Ethernet LANYes
Wi-FiYes
Technical details
Compliance certificatesElectromagnetic Compatibility (EMC)
Other features
Audio output1
BluetoothYes
RS-232 input ports1
