Description

APC Easy UPS On-Line, 2000VA, Lithium-ion, Rack/Tower 2U, 230V, 6 IEC C13 outlets, Intelligent Card Slot, W/ rail kit, Double-conversion (Online), 2 kVA, 1800 W, Sine, 110 V, 300 V

This APC Single phase Easy UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 2000VA double-conversion on-line lithium-ion 2U UPS provides pure sine wave power to support critical electronics during power disruptions. The SRVL comes with IEC 320 C20 input and 6x IEC 320 C13 outlets. The On-Line UPS has a intelligent card slot for optional Network Management Card (AP9544, SRVSMB001, VGL9601l) that enables network-based UPS monitoring and management. With purchased Network Management Card and license, the UPS can connect to EcoStruxure IT or third-party centralized management platforms. The Built-in automatic and manual bypass provide seamless power to the load even in the event of an internal detected fault or error in UPS. The Emergency Power Off (EPO) function can remotely shut off the UPS in an emergency. It comes with a 5-year warranty. The SRVL comes with a easy-to-read 90 degree rotatable LCD display for detailed and accurate information on UPS status. This lithium-ion UPS is ideal for Surveillance, Co-working space, Healthcare IT, ATMs, Micro Data centers, and Server rooms.

Specifications

BrandAPC
Manufacturer part no.SRVL2KRIRK
Our part no.CQ90086
EAN0731304621898
CategoryPower & UPS › UPS
Weight22.7 kg
Features
UPS topologyDouble-conversion (Online)
Output power capacity2 kVA
Output power1800 W
WaveformSine
Input operation voltage (min)110 V
Input operation voltage (max)300 V
Input frequency40 - 70 Hz
Output operation voltage (max)230 V
Output frequency50/60 Hz
Surge energy rating945 J
Heat dissipation683 BTU/h
Number of input phases1
Number of output phases1
Single-phase input voltage supported230 V
Efficiency90%
Crest factor3:1
ECO modeYes
Emergency Power Off (EPO)Yes
Noise level50 dB
Audible alarm(s)Yes
Audible alarm modesLow battery alarm, Overload alarm
Power source typeAC
Detachable power cordYes
Ports & interfaces
AC outlet typesC13 coupler
Power plugC20 coupler
AC outlets quantity6 AC outlet(s)
USB portYes
USB port typeUSB Type-B
Serial interfaceYes
Serial interface typeRS-232
RS-232 ports1
Modem (RJ-11) ports1
Ethernet LAN (RJ-45) ports1
Emergency Power Off (EPO) connectorYes
Battery
Battery technologyLithium-Ion (Li-Ion)
Battery voltage48 V
Typical backup time at full load10.1 min
Battery life (max)10 year(s)
Battery recharge time1.5 h
Replacement battery cartridgeRBCV182-LI
Design
Form factorRackmount/Tower
Rack capacity2U
Cooling typeActive
Built-in fanYes
Product colourBlack, Silver
Control typeButtons
Display typeLCD
LED indicatorsYes
International Protection (IP) codeIP20
Operational conditions
Storage temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 15000 m
Certificates
Waste Electrical and Electronic Equipment (WEEE) complianceYes
Compliance certificatesRoHS, REACH, WEEE
CertificationCB; CE; UKCA; UN 38.3; IEC 62619
Packaging content
Rack mount kitYes
Cables includedOutput power cable, Phone (RJ-11), RJ-45, RS-232, USB cable
Technical details
Sustainable packagingNo
Take-back systemNo
Packaging without single use plasticNo
Weight & dimensions
Width438 mm
Depth502 mm
Height86 mm
Weight16.5 kg
Packaging data
Package width580 mm
Package depth650 mm
Package height240 mm
Package weight22.7 kg
Logistics data
Customs product code (TARIC)8504409590
Total carbon footprint (kg of CO2e)4486.406725093901
Country of originChina
Other features
Input connection typeIEC 60320 C20
Output connection type6 IEC 60320C13
Output voltage230 V
Mountinghorizontal and vertical
