Description
DELL Pro Max GB10 FCM1253, GB10, 128 GB, LPDDR5x-SDRAM, 4 TB, SSD, DGX OS
Compact design for optimized AI workloads Dell Pro Max with GB10 an AI Accelerator provides compact design with powerful performance for local AI inferencing, AI development, and versatile Edge use cases.
Specifications
| Brand | DELL EMC |
|---|---|
| Manufacturer part no. | CD2J8 |
| Our part no. | CQ93145 |
| EAN | 5397184987070 |
| Category | Computers & Servers › Desktop PCs |
| Weight | 0 kg |
| Processor | |
| Processor manufacturer | Nvidia |
| Processor model | GB10 |
| Processor cores | 20 |
| Processor cache | 16 MB |
| Neural processor unit (NPU) | |
| NPU performance up to | 13 TOPs |
| Memory | |
| Internal memory | 128 GB |
| Maximum internal memory | 128 GB |
| Internal memory type | LPDDR5x-SDRAM |
| Memory data transfer rate | 8533 MT/s |
| Storage | |
| Total storage capacity | 4 TB |
| Storage media | SSD |
| Optical drive type | No |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 4 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 4 TB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | NVIDIA |
| On-board graphics card model | NVIDIA Blackwell |
| Performance | |
| Trusted Platform Module (TPM) | Yes |
| Product type | Mini PC |
| Trusted Platform Module (TPM) version | 2.0 |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000,10000 Mbit/s |
| LAN controller | NVIDIA ConnectX-7 |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| WLAN controller manufacturer | AzureWare |
| Bluetooth | Yes |
| Ports & interfaces | |
| USB 3.2 Gen 2x2 Type-C ports quantity | 3 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 2.1a |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Power supply | 280 W |
| Power supply input voltage | 100 - 240 V |
| Design | |
| Product colour | Black |
| Software | |
| Operating system installed | DGX OS |
| Display | |
| Display included | No |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | -15.2 - 3048 m |
| Non-operating altitude | -15.2 - 10668 m |
| Operating vibration | 0.66 G |
| Non-operating vibration | 1.3 G |
| Operating shock | 110 G |
| Non-operating shock | 160 G |
| Weight & dimensions | |
| Width | 150 mm |
| Depth | 150 mm |
| Height | 51 mm |
| Weight | 1.34 kg |
| Packaging content | |
| Box contents | E5 Power Cord 1M for Europe |
| Sustainability | |
| Doesn't contain | PVC/BFR |
| Carbon footprint | |
| Total carbon footprint (kg of CO2e) | 427 |
| Total carbon emissions, standard deviation (kg of CO2e) | 110 |
| Carbon emissions, manufacturing (kg of CO2e) | 258.76 |
| Carbon emissions, logistics (kg of CO2e) | 61.49 |
| Carbon emissions, energy usage (kg of CO2e) | 99.06 |
| Carbon emissions, end-of-life (kg of CO2e) | 7.69 |
| PAIA version | PAIA 1.5.1, 2025 |
