Description
Lenovo ThinkSmart Tiny Kit + Controller, Intel® Core™ i3, i3-13100T, 16 GB, 256 GB, Windows 11 IoT Enterprise, 64-bit
Transform your meeting room into a productive, hassle-free Microsoft Teams Rooms experience with the Lenovo ThinkSmart Tiny Kit. Powered by 13th Gen Intel® Core™ i3 Processor and Windows 11, this dedicated Teams Rooms solution offers an inclusive collaboration space with Realtek® ALC256VB HD audio, video, and native Microsoft applications—all while keeping your laptop free for other tasks. Additionally, this compact device comes with 16GB DDR4-3200 RAM enabling users to handle multiple applications and processes simultaneously without lag. This is beneficial during video conferences, where participants might share presentations, documents, or collaborate on cloud applications in real time.
Specifications
| Brand | LENOVO |
|---|---|
| Manufacturer part no. | 12XH000BUK |
| Our part no. | CR79962 |
| EAN | 0199275309403 |
| Category | Computers & Servers › Desktop PCs |
| Weight | 5.1 kg |
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i3 |
| Processor generation | Intel Core i3-13xxx |
| Processor model | i3-13100T |
| Processor cores | 4 |
| Processor threads | 8 |
| Processor boost frequency | 4.2 GHz |
| Performance cores | 4 |
| Performance-core Max Turbo Frequency | 4.2 GHz |
| Performance-core base frequency | 2.5 GHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Processor base power | 35 W |
| Maximum turbo power | 69 W |
| Memory | |
| Internal memory | 16 GB |
| Maximum internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 2 x 8 GB |
| Memory slots | 2x SO-DIMM |
| Memory clock speed | 3200 MHz |
| Memory channels | Dual-channel |
| Storage | |
| Total storage capacity | 256 GB |
| Storage media | SSD |
| Optical drive type | No |
| Number of storage drives installed | 1 |
| Total SSDs capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card model | Intel UHD Graphics 730 |
| Performance | |
| Motherboard chipset | Intel Q670 |
| Password protection | Yes |
| Password protection type | BIOS, HDD, Power on, Supervisor |
| Trusted Platform Module (TPM) | Yes |
| Product type | Mini PC |
| Trusted Platform Module (TPM) version | 2.0 |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Power | |
| Power supply | 90 W |
| Design | |
| Chassis type | Mini PC |
| VESA mounting | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Software | |
| Operating system architecture | 64-bit |
| Operating system language | English |
| Operating system installed | Windows 11 IoT Enterprise |
| Display | |
| Display included | Yes |
| Display diagonal | 25.6 cm (10.1") |
| Display resolution | 1280 x 800 pixels |
| Native aspect ratio | 16:10 |
| Display brightness | 340 cd/m² |
| Audio | |
| Audio chip | Realtek ALC256-VB |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12192 m |
| Weight & dimensions | |
| Width | 179 mm |
| Depth | 182.9 mm |
| Height | 36.5 mm |
| Weight | 2.65 kg |
| Packaging data | |
| Package width | 313 mm |
| Package depth | 242 mm |
| Package height | 327 mm |
| Package weight | 4.9 kg |
| Packaging content | |
| Box contents | HDMI Ingest Dongle |
