Description
Lindy 73474, IEEE 802.3bt, IEEE 802.3at, IEEE 802.3af, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, 10/100/1000Base-T(X), Black, Plastic, Status, 0 - 40 °C
This converter provides up to 45W power and gigabit Ethernet data from a PoE signal.
The input signal is split into Type-C and RJ45 outputs, allowing connection to non-PoE devices such as access points, routers, cameras, laptops, tablets, and more.
It can convert PoE, PoE+ High Power, and Ultra PoE++ connections, ensuring compatibility with a wide range of Power over Ethernet switches and devices.
The USB-C output voltage is automatically adjusted and supports 5V/3.4A, 9V/3A, 12V/3A, 15V/3A, and 20V/2.25A.
This compact and high efficiency power converter provides also over voltage, over current and short circuit protection with over temperature cut off while the installation is plug and play without any external power supply; the converter is self-powered from the PoE input. A status LED indicates when input power is detected.
Specifications
| Brand | LINDY ELECTRONICS |
|---|---|
| Manufacturer part no. | 73474 |
| Our part no. | CR85999 |
| EAN | 4002888734745 |
| Category | Networking › Transceivers & SFPs |
| Weight | 0.1 kg |
| Features | |
| Networking standards | IEEE 802.3bt, IEEE 802.3at, IEEE 802.3af, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Cabling technology | 10/100/1000Base-T(X) |
| Power over Ethernet (PoE) | Yes |
| Product colour | Black |
| Housing material | Plastic |
| LED indicators | Status |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| USB Type-C output ports | 1 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Certificates | |
| Compliance certificates | CE, REACH, RoHS |
| Weight & dimensions | |
| Width | 80 mm |
| Depth | 54 mm |
| Height | 24 mm |
| Weight | 85 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Packaging data | |
| Package weight | 110 g |
| Package type | Box |
| Power | |
| USB Power Delivery (USB PD) | Yes |
