Description
Lenovo ThinkCentre M70a Gen 6, 60.5 cm (23.8"), Full HD, Intel Core Ultra 5, 16 GB, 512 GB, Windows 11 Pro
- Superior AI-driven performance with Intel® Core™ Ultra processors - 23.8″ AIO PC offering personalized experiences with intelligent AI features - Robust security, advanced connectivity & ample storage for multitasking
Specifications
| Brand | LENOVO |
|---|---|
| Manufacturer part no. | 13AY001JUK |
| Our part no. | CS60377 |
| EAN | 0198157076655 |
| Category | Computers & Servers › Desktop PCs |
| Weight | 0 kg |
| Display | |
| Display diagonal | 60.5 cm (23.8") |
| Display resolution | 1920 x 1080 pixels |
| Touchscreen | No |
| HD type | Full HD |
| Native aspect ratio | 16:9 |
| Display brightness | 250 cd/m² |
| Panel type | IPS |
| RGB colour space | sRGB |
| Anti-glare screen | Yes |
| Low Blue Light technology | Yes |
| Colour gamut | 99% |
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 5 |
| Processor generation | Intel Core Ultra (Series 2) |
| Processor model | 225T |
| Processor cores | 10 |
| Processor threads | 10 |
| Processor boost frequency | 4.9 GHz |
| Performance cores | 6 |
| Efficient cores | 4 |
| Performance-core Max Turbo Frequency | 4.9 GHz |
| Efficient-core Max Turbo Frequency | 4.4 GHz |
| Performance-core base frequency | 2.5 GHz |
| Efficient-core base frequency | 1.9 GHz |
| Processor cache | 20 MB |
| Processor cache type | Smart Cache |
| Processor socket | LGA 1851 (Socket V1) |
| Processor base power | 35 W |
| Maximum turbo power | 114 W |
| Neural processor unit (NPU) | |
| Neural processor unit (NPU) | Intel AI Boost |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI software frameworks supported by NPU | DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to | 23 TOPs |
| NPU performance up to | 13 TOPs |
| GPU performance up to | 4 TOPs |
| Memory | |
| Internal memory | 16 GB |
| Internal memory type | DDR5-SDRAM |
| Maximum internal memory | 64 GB |
| Memory slots | 2 |
| Memory slots type | SO-DIMM |
| Memory clock speed | 5600 MHz |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory form factor | DIMM/SO-DIMM |
| Storage | |
| Total storage capacity | 512 GB |
| Storage media | SSD |
| Total SSDs capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | PCI Express 4.0 |
| NVMe | Yes |
| SSD form factor | M.2 |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Optical drive type | No |
| Card reader integrated | Yes |
| Graphics | |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card | Yes |
| On-board GPU manufacturer | Intel |
| On-board graphics card family | Intel® Graphics |
| On-board graphics card model | Intel® Graphics |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| RMS rated power | 4 W |
| Built-in microphone | Yes |
| Number of microphones | 2 |
| Camera | |
| Built-in camera | Yes |
| Total megapixels | 5 MP |
| Privacy camera | Yes |
| Privacy type | Privacy shutter |
| Network | |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Antenna type | 2x2 |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Combo headphone/mic port | Yes |
| Design | |
| Product colour | Black |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Performance | |
| Product type | All-in-One PC |
| Motherboard chipset | Intel® Q870 |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
| Operating system language | English |
| Operating system installed | Windows 11 Pro |
| Processor special features | |
| Intel® Smart Cache | Yes |
| Power | |
| AC adapter power | 90 W |
| Weight & dimensions | |
| Width (with stand) | 539.6 mm |
| Depth (with stand) | 222.2 mm |
| Weight (with stand) | 8.08 kg |
| Sustainability | |
| Sustainability certificates | ENERGY STAR, TCO, TCO10, EPEAT Gold, ErP, GREENGUARD |
| Packaging content | |
| Mouse included | Yes |
| Mouse connectivity | Wired |
| Keyboard included | Yes |
| Keyboard connectivity | Wired |
| Keyboard language | UK English |
| Other features | |
| Ethernet interface type | Gigabit Ethernet |
| Graphics card | Intel Graphics |
| Fingerprint reader | No |
| Security chip | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
