Description
Origin Storage SSD 1TB 2.5in SATA 3D TLC in 3.5in Converter incl cables, 1 TB, 3.5", 550 MB/s, 6 Gbit/s
Origin Storage Ltd manufactures a full range of Matched SSD Solutions for most major branded Servers, laptops and desktops, such as Dell, HP, Toshiba, and Lenovo. All of our Matched SSD Solutions come with up to 5 years advanced replacement warranty and also come with free pre and post sales technical support. We can supply replacements or upgrades in form factors of 2.5" or 3.5", M.2 & AIC with either SATA, SAS or PCIe interfaces respectively, available in a range of capacities and drive write endurances for laptop, desktop or Server. All our Matched SSD Solutions are just that, matched to the system you have for 100% compatibility, right first time, every time!
Specifications
| Brand | ORIGIN STORAGE |
|---|---|
| Manufacturer part no. | DELL-1000TLC-BWC |
| Our part no. | M158087 |
| EAN | 5056006103523 |
| Category | Hard Drives & SSDs › SSDs |
| Weight | 0.2 kg |
| Features | |
| NAND flash type | TLC (Triple Level Cell) |
| Security algorithms | 256-bit AES |
| SSD capacity | 1 TB |
| SSD form factor | 3.5" |
| Interface | Serial ATA |
| NVMe | No |
| Memory type | QLC |
| Component for | PC/Laptop |
| Hardware encryption | No |
| Data transfer rate | 6 Gbit/s |
| Read speed | 550 MB/s |
| Write speed | 500 MB/s |
| Random read (4KB) | 53760 IOPS |
| Random write (4KB) | 56320 IOPS |
| Access time | 0.1 ms |
| Seek time | 0 ms |
| Controller type | Samsung MGX |
| DevSlp (device sleep) support | Yes |
| S.M.A.R.T. support | Yes |
| TRIM support | Yes |
| Hot-swap | No |
| IEEE 1667 | Yes |
| Mean time between failures (MTBF) | 1000000 h |
| Active garbage collection | Yes |
| Windows operating systems supported | Yes |
| Opal SSC 2.0 | Yes |
| Linux operating systems supported | Yes |
| TBW rating | 100 |
| Power | |
| Operating voltage | 5 V |
| Power consumption (read) | 2.8 W |
| Power consumption (write) | 4.26 W |
| Power consumption (max) | 4.26 W |
| Power consumption (average) | 3.53 W |
| Power consumption (idle) | 0.54 W |
| Weight & dimensions | |
| Width | 69.8 mm |
| Depth | 100.5 mm |
| Height | 7 mm |
| Packaging data | |
| Storage drive adapter included | No |
| Screws included | No |
| Package type | Blister |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -45 - 105 °C |
| Operating relative humidity (H-H) | 5 - 98% |
| Storage relative humidity (H-H) | 5 - 98% |
| Operating vibration | 16 G |
| Non-operating vibration | 20 G |
| Operating shock | 1500 G |
| Non-operating shock | 1500 G |
| Maximum operating altitude | 36576 m |
| Other features | |
| Warranty period | 5 year(s) |
| Compliance certificates | RoHS |
| Compatible products | Universal |
| Logistics data | |
| Harmonized System (HS) code | 84717070 |
