Description

StarTech.com DisplayPort to DVI Adapter - Active DisplayPort to DVI-D Adapter/Video Converter 1080p - DP 1.2 to DVI Monitor Cable Adapter Dongle - DP to DVI Adapter - Latching DP Connector, 0.2 m, DisplayPort, DVI-D, Male, Female, Straight

Connect a DVI monitor to a single-mode DisplayPort output from your computer

The DP2DVIS DisplayPort to DVI Active Single Link adapter lets you connect your DisplayPort video source (desktop PC, laptop, etc.) to a DVI-D monitor, projector or display, including televisions and Apple Cinema Display HD, eliminating the expense of having to upgrade to a DisplayPort-capable monitor.

Unlike passive adapters, this DP to DVI converter offers an active conversion for use with any DisplayPort output - ideal for graphics cards that are not capable of outputting multi-mode DP++ signals (e.g. ATI Eyefinity). Supporting resolutions up to 1920x1200, this compact device provides a simple solution for converting DisplayPort output for compatibility with existing DVI monitors, televisions or projectors.

Backed by a StarTech.com 3-year warranty and free lifetime technical support.

The StarTech.com Advantage

Specifications

BrandSTARTECH
Manufacturer part no.DP2DVIS
Our part no.V931316
EAN0065030842327
CategoryCables & Adapters › VGA & Video Adapters
Weight0 kg
Features
Connector 1 form factorStraight
Connector 2 form factorStraight
Cable length0.2 m
Connector 1DisplayPort
Connector 2DVI-D
Connector 1 genderMale
Connector 2 genderFemale
HDCPYes
HDCP version1.3
DisplayPort version1.2
Dual Link DVINo
Product colourBlack
ChipsetParade PS 161
Converter typeActive video converter
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)0 - 70 °C
Operating relative humidity (H-H)80 - 90%
Storage relative humidity (H-H)80 - 90%
Weight & dimensions
Weight48 g
Width44 mm
Depth200 mm
Height20 mm
Packaging data
Package width200 mm
Package depth220 mm
Package height20 mm
Package weight57 g
Logistics data
Harmonized System (HS) code84733080
Master (outer) case width337 mm
Master (outer) case length496 mm
Master (outer) case height226 mm
Products per master (outer) case90 pc(s)
