Basket

Description

StarTech.com Cisco GLC-FE-100FX Compatible SFP Module - 100BASE-FX - 100Mbps Multimode Fiber MMF Optic Transceiver - 100 Mbps - LC 2km - 1310nm - DDM Cisco ASR920, IE2000, IE4000, Fiber optic, 155 Mbit/s, SFP, LC, FX, 2000 m

100 Mbps | Multi Mode Fiber | LC | 2 km (1.2 mi) | Lifetime Warranty

The SFPF1302C is a Cisco GLC-FE-100FX compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco® brand switches and routers. It delivers dependable 100 Mb connectivity over fiber cable, for 100BASE-FX compliant networks, with a maximum distance of up to 2 km (1.2 mi).

Technical Specifications:

• Wavelength: 1310nm • Maximum Data Transfer Rate: 155 Mbps • Type: Multimode Fiber • Connection Type: LC Connector • Maximum Transfer Distance: 2 km (1.2 mi) • MTBF: 1,472,572 hours • Power Consumption: Less than 1 Watt • Digital Diagnostics Monitoring (DDM): Yes

This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

Specifications

BrandSTARTECH
Manufacturer part no.SFPF1302C
Our part no.V931908
EAN0065030846370
CategoryNetworking › Transceivers & SFPs
Weight0 kg
Performance
SFP transceiver typeFiber optic
Maximum data transfer rate155 Mbit/s
Interface typeSFP
Multi-mode fiber (MMF) supportedYes
Fiber optic connectorLC
SFP transceiver standardFX
Maximum transfer distance2000 m
Wavelength1300 nm
Networking standardsIEEE 802.3u
Duplex systemFull, Half
Digital Diagnostics Monitoring (DDM)Yes
Wavelength-division multiplexing (WDM)No
Features
Product colourSilver
Hot-swapYes
Mean time between failures (MTBF)1472572 h
Power
Power consumption (typical)1 W
Certificates
Compliance certificatesRoHS
CertificationCE, FCC, UL
Operational conditions
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)30 - 70%
Weight & dimensions
Width9 mm
Depth65 mm
Height14 mm
Weight25 g
Packaging content
Quantity per pack1 pc(s)
Packaging data
Package width113 mm
Package depth92 mm
Package height33 mm
Package weight95 g
Logistics data
Master (outer) case width260 mm
Master (outer) case length308 mm
Harmonized System (HS) code85369010
Master (outer) case height201 mm
Products per master (outer) case36 pc(s)
