Description
StarTech.com DisplayPort to DVI Dual Link Active Adapter - DisplayPort to DVI-D Adapter Video Converter 2560x1600 60Hz - DP 1.2 to DVI Monitor - USB Powered - Latching DP Connector, 0.37 m, DisplayPort, DVI-D, Male, Female, Straight
Connect your DVI Dual Link display to a DisplayPort® video source, for high resolution applications
The DP2DVID2 DisplayPort® to DVI (Dual-Link) Adapter actively converts the output signal from a DisplayPort video source for use with a DVI-D display (monitor, etc.) or projector, helping to eliminate the equipment costs of upgrading a DVI display to a newer model for the sake of compatibility.
The adapter supports high resolution video (up to 2560x1600 at 60Hz), maintaining the outstanding graphical performance from a DisplayPort-equipped desktop video card, laptop or MacBook®.
DP2DVID2 performs an active DisplayPort-DVI conversion that is suitable for video sources that output either multimode (DP++) or single-mode DisplayPort signals. This ensures the adapter can be used even with graphics cards that aren't capable of outputting multimode DP++ signals, such as ATI® Eyefinity cards.
Back by StarTech.com 3-year warranty, with free lifetime technical support.
The StarTech.com Advantage
Specifications
| Brand | STARTECH |
|---|---|
| Manufacturer part no. | DP2DVID2 |
| Our part no. | V932197 |
| EAN | 0065030848749 |
| Category | Cables & Adapters › VGA & Video Adapters |
| Weight | 0.2 kg |
| Features | |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Power source | USB |
| Cable length | 0.37 m |
| Connector 1 | DisplayPort |
| Connector 2 | DVI-D |
| Connector 1 gender | Male |
| Connector 2 gender | Female |
| HDCP | Yes |
| DisplayPort version | 1.2 |
| Dual Link DVI | Yes |
| Maximum resolution | 2560 x 1600 pixels |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA) |
| Maximum refresh rate | 120 Hz |
| HBR2 support | Yes |
| Product colour | Black |
| Converter type | Active video converter |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Certificates | |
| Compliance certificates | CE, RoHS |
| Certification | RoHS |
| Weight & dimensions | |
| Weight | 160 g |
| Width | 64 mm |
| Depth | 549 mm |
| Height | 22 mm |
| Packaging data | |
| Package width | 174 mm |
| Package depth | 143 mm |
| Package height | 35 mm |
| Package weight | 232 g |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| Master (outer) case width | 337 mm |
| Master (outer) case length | 497 mm |
| Master (outer) case height | 220 mm |
| Products per master (outer) case | 28 pc(s) |
