StarTech.com Cisco SFP-GE-S Compatible SFP Module - 1000BASE-SX - 1GbE Multimode Fiber MMF Optic Transceiver - 1GE Gigabit Ethernet SFP - LC 550m - 850nm - DDM Cisco IE3400, IE3300, IE3200, Fiber optic, 1250 Mbit/s, SFP, LC, SX, 550 m

1000 Mbps (1 Gbps) | Multi Mode Fiber | LC | 550 m (1804 ft) | Lifetime Warranty

The SFPGESST is a Cisco SFP-GE-S compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco® brand switches and routers. It delivers dependable 1 GbE connectivity over fiber cable, for 1000BASE-SX compliant networks, with a maximum distance of up to 550 m (1804 ft).

Technical Specifications:

• Wavelength: 850nm • Maximum Data Transfer Rate: 1.25 Gbps • Type: Multi Mode Fiber • Connection Type: LC Connector • Maximum Transfer Distance: 550 m (1804 ft) • MTBF: 3,381,761 hours • Power Consumption: Less than 1 Watt • Digital Diagnostics Monitoring (DDM): Yes

This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.

Specifications

BrandSTARTECH
Manufacturer part no.SFPGESST
Our part no.V932204
EAN0065030849432
CategoryNetworking › Transceivers & SFPs
Weight0 kg
Performance
SFP transceiver typeFiber optic
Maximum data transfer rate1250 Mbit/s
Interface typeSFP
Multi-mode fiber (MMF) supportedYes
Fiber optic connectorLC
SFP transceiver standardSX
Maximum transfer distance550 m
Wavelength850 nm
Networking standardsIEEE 802.3z
Duplex systemFull, Half
Digital Diagnostics Monitoring (DDM)Yes
Wavelength-division multiplexing (WDM)No
Features
Product colourSilver
Hot-swapYes
Mean time between failures (MTBF)3381761 h
Brand compatibilityCisco
Compatible productsSFP-GE-S
Power
Power consumption (typical)1 W
Certificates
Compliance certificatesRoHS
CertificationCE, FCC, UL, REACH
Operational conditions
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)30 - 70%
Weight & dimensions
Width12 mm
Depth60 mm
Height10 mm
Weight17 g
Packaging content
Quantity per pack1 pc(s)
Packaging data
Package width92 mm
Package depth114 mm
Package height33 mm
Package weight95 g
Logistics data
Master (outer) case width208 mm
Master (outer) case length310 mm
Harmonized System (HS) code85369010
Master (outer) case height254 mm
Products per master (outer) case36 pc(s)
